Rittal TS 8614.680 Partial Mounting Plate - 2.5 mm Zinc-Plated
Part Number: 8614680
Quick Summary
Rittal TS 8614.680 partial mounting plate enables universal interior installation for TS and VX SE enclosures. It tackles the common retrofit downtime by adding mounting levels quickly without major rework. Although formal CE, SIL or IP certifications aren’t listed, the plate’s 2.5 mm zinc-plated sheet steel and the included inner mounting level deliver robust, field-ready performance. This design supports scalable cabinet configurations and simplifies maintenance for teams using TS enclosure accessories and related mounting systems.
Product Information
Extended Description
8614680 Rittal: TS Partial mounting plate, for TS, SE, W/DH: 500x700 mm
Article number
TS 8614.680
Product description
For universal interior installation, also in conjunction with punched sections with mounting flanges and support strips. Defective assemblies are quickly and easily replaced. Additional mounting levels.
Material
Sheet steel, 2.5 mm
Surface finish
Zinc-plated
Supply includes
Assembly parts
Note
Partial mounting plates are fastened directly onto the vertical enclosure sections via the inner mounting level using the assembly parts supplied loose. In this mounting position (in both the width and the depth) they form one level with TS punched sections with mounting flanges 17 x 73 mm and TS support strips for the inner mounting level.
Dimensions
Width: 500 mm | Height: 700 mm
To fit
Enclosure type: TS | VX SE | Width: = 600 mm | = 800 mm | Depth: = 600 mm | = 800 mm
Packs of
1 pc(s).
Weight/pack
11.65 kg
Customs tariff number
94039910
EAN
4028177212381
ETIM 9
EC000213
ECLASS 8.0
27409216
Product description
TS Partial mounting plate, for TS, SE, W/DH: 500x700 mm
The plate provides universal interior installation for TS and VX SE enclosures and integrates with punched sections with mounting flanges and support strips, enabling flexible inner mounting levels. This translates to faster setup, reduced labor costs, and easier future upgrades on active lines. Constructed from 2.5 mm sheet steel and zinc-plated, it offers corrosion resistance in demanding environments, lowering maintenance needs and extending service life for critical control panels. Supply includes assembly parts, so technicians can complete installations with fewer trips to the parts bin, cutting downtime and minimizing project delays. Weighing 11.65 kg per pack and sized at 500x700 mm, it delivers solid support without complicating transport or handling. Compatibility with TS and VX SE footprints of 600 or 800 mm width and 600 or 800 mm depth reduces SKU proliferation and accelerates procurement. The installation note confirms direct fastening to vertical enclosure sections via the inner mounting level, aligning with TS punched sections and support strips for a seamless, single-plane assembly.
