Rittal TS 8614.850 Partial mounting plate - 700x400
Part Number: 8614850
Quick Summary
Partial mounting plate TS 8614.850 from Rittal enables flexible interior mounting for TS, SE, and VX enclosure systems. This solution addresses the common challenge of maximizing available space while keeping systems modular and easy to reconfigure. By supporting an additional mounting level and allowing quick replacement of defective assemblies, it minimizes downtime and labor costs on busy lines. The design aligns with ETIM 9 EC000213 and ECLASS 8.0 27409216 data standards, ensuring seamless procurement and consistent part data. In practice, the plate complements punched sections with mounting flanges and support strips, delivering reliable integration with existing TS infrastructure. For buying teams, it also offers straightforward sourcing and compatibility with standard enclosure accessories for scalable automation architectures.
Product Information
Extended Description
8614850 Rittal: TS Partial mounting plate, for TS, SE, W/DH: 700x400 mm
Article number
TS 8614.850
Product description
For universal interior installation, also in conjunction with punched sections with mounting flanges and support strips. Defective assemblies are quickly and easily replaced. Additional mounting levels.
Material
Sheet steel, 2.5 mm
Surface finish
Zinc-plated
Supply includes
Assembly parts
Note
Partial mounting plates are fastened directly onto the vertical enclosure sections via the inner mounting level using the assembly parts supplied loose. In this mounting position (in both the width and the depth) they form one level with TS punched sections with mounting flanges 17 x 73 mm and TS support strips for the inner mounting level.
Dimensions
Width: 700 mm | Height: 400 mm
To fit
Enclosure type: TS | VX SE | Width: = 800 mm | Depth: = 500 mm | = 800 mm
Packs of
1 pc(s).
Weight/pack
7 kg
Customs tariff number
94039910
EAN
4028177212350
ETIM 9
EC000213
ECLASS 8.0
27409216
Product description
TS Partial mounting plate, for TS, SE, W/DH: 700x400 mm
Feature: 700x400 mm dimensions provide a broad, ready-made interior mounting area. Business Impact: maximizes mounting efficiency and reduces the need for custom fabrication, accelerating project timelines. Application: Ideal for TS, SE, and W/DH enclosures in control cabinet upgrades and retrofits. Feature: Sheet steel, 2.5 mm core with zinc‑plated surface. Business Impact: high rigidity and corrosion resistance translate to longer service life in harsh industrial environments. Application: Suitable for residential to heavy-duty panel builds where reliability matters most.Feature: Additional mounting level with supplied assembly parts. Business Impact: enables a second tier of components and easier organization of cabling and devices, cutting installation time by eliminating workaround solutions. Application: Useful where space is tight and multiple devices must be mounted without expanding enclosure width.Feature: Direct fastening to vertical enclosure sections via inner mounting level. Business Impact: flush alignment with existing TS punched sections improves accessibility and reduces mounting tolerances, lowering stress on mounted equipment. Application: Compatible with mounting flanges 17 x 73 mm and TS support strips for inner levels.Feature: Universal fit for TS, VX SE and W/DH enclosures. Business Impact: simplifies procurement by aligning with common enclosure families, reducing SKU proliferation. Application: Great for scalable automation projects and multi-line installations.Feature: Includes assembly parts and follows standard dimensions. Business Impact: minimizes field sourcing overhead and speeds up on-site assembly, reducing total cost of ownership. Application: Fits typical production environments where maintenance teams require rapid replacements and reconfiguration.
