Rittal VX 8617.505 VX Baying Kit - IP54, 8-bay extension
Part Number: 8617505
Quick Summary
The Rittal VX baying kit enables seamless extension of VX/TS enclosures for 8-bay configurations in industrial control panels. Without proper baying, gaps and misalignment can compromise enclosure integrity and drive costly rework. The kit is CE-certified and delivers IP54 protection when used with the baying cover and top, while aligning with ETIM EC002622 and ECLASS 27189263 Classifications to support your procurement data. As a compatible enclosure accessory, it simplifies VX/TS interoperability, reduces installation time, and lowers stocking complexity by providing a single, verified solution for expanding existing suites. This minimizes project risk, ensures regulatory compliance, and supports scalable automation deployments.
Product Information
Extended Description
8617505 Rittal: VX baying kit for VX / TS
Article number
VX 8617.505
Product description
For extending existing TS 8 bayed enclosure suites with VX25 enclosures.
Material
Baying connector: Sheet steel
Supply includes
8 baying connectors | 1 seal | Assembly parts
Note
IP 54 in conjunction with baying cover, top
To fit
Enclosure type: VX | TS
Packs of
1 pc(s).
Weight/pack
1.6 kg
Customs tariff number
73269098
EAN
4028177930889
ETIM 9
EC002622
ECLASS 8.0
27189263
Product description
VX baying kit for VX / TS
Feature: VX baying kit enables the extension of TS 8-bay enclosure suites by adding VX25 modules. Impact: This delivers faster assembly, aligned bay frames, and consistent electrical clearances, reducing commissioning risk for control panels. Application: Use when expanding legacy TS configurations to VX-based modules to create compact, scalable automation layouts on factory floors and in data centers. Feature: Sheet steel baying connectors provide robust mechanical joints. Impact: Enhances durability in vibration-prone environments and maintains alignment over life cycles. Application: Suitable for VX/TS bays in harsh industrial settings, including manufacturing, packaging, and process automation. Feature: Supply includes eight baying connectors, one seal, and assembly parts. Impact: Simplifies procurement and reduces on-site errors. Application: Facilitates a one-kit upgrade path for existing enclosures. Feature: To fit VX and TS enclosure types. Impact: Ensures compatibility across common Rittal cabinets. Application: Ideal for upgrading existing 8-bay suites without replacing full enclosures. Feature: IP54 protection is achieved in conjunction with the baying cover and top. Impact: Helps maintain uptime in dusty or damp environments. Application: Factory floors, paint shops, and harsh industrial areas. Feature: CE certification, ETIM EC002622, and ECLASS 27189263 alignment. Impact: Supports regulatory compliance and standardized procurement data. Application: Helps OEMs and integrators maintain consistent BOMs and sourcing. Feature: Weight per pack is 1.6 kg; packs are 1 piece each. Impact: Simplifies logistics and stocking strategies. Application: Quick on-site handling and predictable warehouse planning.
Get a Quick Quote for a Rittal 8617505
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8617505?
Enquire Now
FAQs
The VX baying kit is designed to fit VX and TS enclosure types, enabling the extension of existing TS eight-bay suites with VX25 modules. Each pack includes eight baying connectors, one seal, and assembly parts, and is sold as a single 1-piece pack weighing 1.6 kg, simplifying procurement and on-site assembly.
IP54 protection is achieved when the baying kit is used in conjunction with the baying cover and top. Without those components, protection level may vary. The kit maintains enclosure integrity in dusty or damp environments, reducing ingress and splash risks during operation and service.
Yes. The pre-fabricated baying connectors and included seal and assembly parts streamline alignment and fastening, cutting on-site installation time. The compatibility with VX/TS enclosures avoids custom fabrication and rework, enabling faster commissioning of expanded automation panels and reducing risk of misalignment.
The kit is CE-compliant for European markets and provides IP54 protection when used with the baying cover and top. It is classified under ETIM EC002622 and ECLASS 27189263, supporting standardized data exchange, regulatory compliance, and accurate procurement across engineering and purchasing teams.
The kit is sold in packs of 1 piece with a weight of 1.6 kg per pack, simplifying inventory planning. Each order contains eight baying connectors, one seal, and assembly parts. This packaging and content supports straightforward stocking alongside other VX/TS installation components and enables efficient on-site handling.
