Rittal VX 8617.506 Quick-fit baying clamps - Zinc-plated
Part Number: 8617506
Quick Summary
VX 8617.506 is a quick-fit baying clamp system designed for fast, secure baying joint installations in electrical enclosures. This approach reduces assembly time and minimizes misalignment during panel outfitting, addressing a common pain point for installation teams. The clamp design aligns with CE safety expectations and supports IP-rated environments, helping ensure regulatory compliance in European and industrial settings. Beyond safety, the system offers straightforward compatibility with standard baying joints and includes the necessary assembly parts, delivering tangible business value through reduced downtime and lower total cost of ownership. For projects requiring robust mechanical bonding and reliable field performance, VX 8617.506 provides a proven, scalable solution.
Product Information
Extended Description
8617506 Rittal: VX Quick-fit baying clamps
Article number
VX 8617.506
Benefits
For all-round installation on the baying joint
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
Assembly parts
Packs of
6 pc(s).
Weight/pack
0.708 kg
Customs tariff number
83024900
EAN
4028177942332
ETIM 9
EC002622
ECLASS 8.0
27189263
Product description
VX Quick-fit baying clamps
Feature: Quick-fit installation using screws, insert the clamp, tap in with a hammer, then lock. Business Impact: Speeds up on-site assembly, reduces tool requirements, and minimizes human error, delivering time savings on each enclosure build. Application: Ideal for rapid baying joint installations in electrical panels and switchgear. Feature: Material is sheet steel with a zinc-plated surface finish. Business Impact: Delivers robust mechanical strength with corrosion resistance, extending service life in harsh industrial environments. Application: Suitable for outdoor or damp plant rooms where enclosure accessories face exposure to elements. Feature: Supply includes assembly parts and packs of 6 clamps per pack (0.708 kg per pack). Business Impact: Simplifies procurement, improves inventory planning, and lowers logistics complexity for project teams. Application: supports predictable staffing and bulk purchasing for large enclosure projects. Feature: For all-round installation on the baying joint. Business Impact: Ensures a standardized fit, reduces alignment issues, and accelerates commissioning. Application: Compatible with common baying joints across Rittal enclosures and similar systems. Feature: Regulatory reference data (ETIM 9 EC002622; ECLASS 8.0 27189263; EAN 4028177942332) aids procurement and cataloguing. Business Impact: Improves ERP integration, reduces mis-categorization, and speeds part reordering. Application: Streamlines technical purchasing for industrial automation projects.
Get a Quick Quote for a Rittal 8617506
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8617506?
Enquire Now
FAQs
Begin by aligning the clamp with the baying joint, insert the screws, tap the quick-fit clamp with a hammer until seated, and secure with the locking mechanism. The package includes all assembly parts, and the process is designed to minimize misalignment and downtime during enclosure builds.
Yes. The clamps are designed for all-round installation on baying joints and are supplied with assembly parts to ensure a secure fit on standard baying joints used in Rittal enclosures and similar systems, helping to standardize field installations.
The clamps are made from sheet steel with a zinc-plated surface finish, providing mechanical strength and corrosion resistance suitable for industrial environments where enclosure accessories face exposure to moisture or contaminants.
VX 8617.506 is designed to support compliance expectations typical for European and industrial installations, with documentation and cataloging aligned to ETIM EC002622 and ECLASS 27189263 standards. Always verify regional regulatory requirements for your specific project.
Clamps are sold in packs of six, with a total weight of 0.708 kg per pack. This packaging supports efficient bulk purchasing and straightforward inventory management for enclosure assembly projects.
