Rittal VX 8618.822 EMC gland plate - 1000 mm Width
Part Number: 8618822
Quick Summary
The Rittal VX 8618.822 EMC gland plate provides shielded cable grounding and secure fastening for VX enclosure systems. Engineers often struggle to maintain low-resistance EMC contact while controlling installation time and costs. When selecting enclosure accessories, verify CE conformity where required, and note that this model does not provide an IP rating or defined SIL suitability for this passive component. For projects prioritizing EMC performance and quick, tool-friendly installation, this gland plate helps reduce EMI risk and simplifies maintenance. The kit fits VX enclosures of 1,000 mm width and supports 400, 500, 600 and 800 mm deep variants, with included EMC seals to ensure continuous shielding across the interface.
Product Information
Extended Description
8618822 Rittal: VX EMC gland plate, width 1000 mm
Article number
VX 8618.822
Product description
For shielded cables with a maximum diameter of 20 mm. Combined EMC contacting and cable fastening provide low-resistance contact between the cable shield and gland plate. For all 400, 500, 600 and 800 mm deep enclosures in conjunction with standard gland plates.
Material
Sheet steel
Surface finish
Zinc-plated
Supply includes
1 gland plate with T-head punching | 1 sliding gland plate | 2 EMC seals
Note on Model No.
For one enclosure half only
To fit
Enclosure type: VX | Width: = 1,000 mm
Note
Standard-compliant IP protection category not supported
Packs of
1 pc(s).
Weight/pack
1.78 kg
Customs tariff number
73269098
EAN
4028177929869
ETIM 9
EC002620
ECLASS 8.0
27189261
Product description
VX EMC gland plate, width 1000 mm
Feature: Combined EMC contacting and cable fastening provides a low-resistance contact between the cable shield and gland plate. Business Impact: Improves EMI shielding effectiveness and reduces resistance-driven losses, enhancing overall enclosure integrity. Application: Shielded cables up to Ø20 mm in VX enclosures, supporting reliable performance in harsh industrial environments. Feature: 1 gland plate with T-head punching, 1 sliding gland plate, and 2 EMC seals included. Business Impact: Speeds installation, reduces parts handling, and ensures a complete shielding interface out of the box. Application: New builds or retrofits in 400–800 mm deep VX enclosures. Feature: Sheet steel with zinc-plated surface finish. Business Impact: Provides robust mechanical durability and corrosion resistance, lowering maintenance cycles in demanding plants. Application: Industrial installations where long-term shielding and exposure to dust and moisture are considerations. Feature: Width 1,000 mm to fit VX enclosures. Business Impact: Ensures straightforward compatibility with standard VX widths, minimizing customization and lead times. Application: Standardized VX configurations across projects. Feature: Pack contents and weight: 1 pc per pack, weight 1.78 kg. Business Impact: Predictable shipping and handling, simplified inventory management, and consistent installation planning. Application: Warehouse and field installations requiring clear parts counts. Feature: Not IP-rated; note on certifications. Business Impact: Encourages project teams to verify specific regulatory requirements for their region, ensuring appropriate enclosure protection strategies. Application: Projects with stringent IP or regulatory expectations may need additional sealing or enclosure accessories.
Get a Quick Quote for a Rittal 8618822
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8618822?
Enquire Now
FAQs
To install, ensure the VX enclosure is powered down and accessories are compatible. Align the 1,000 mm wide gland plate with the enclosure interface, attach the gland plate with T-head punching, fit the sliding gland plate, and apply the two EMC seals to seal the shield interface. Verify shield continuity and tighten fasteners to specification. This quick-install kit minimizes wiring disruption and supports reliable EMC performance.
The gland plate combines EMC contacting with cable fastening to deliver a low-resistance contact between the cable shield and the gland plate, reducing EMI leakage paths and improving shielding effectiveness. This is especially important for shielded cables up to Ø20 mm in VX enclosure systems, helping you meet EMI/EMC compliance in sensitive automation applications.
Yes. The VX EMC gland plate is designed for VX enclosures and supports all standard depths of 400, 500, 600 and 800 mm when used with standard gland plates. Its 1,000 mm width ensures compatibility with VX frames, enabling straightforward integration across common installation footprints.
Note indicates that standard IP protection is not supported by this gland plate. While CE conformity and other certifications may apply to overall system installations, this component itself does not carry an IP rating. Always verify your project’s regulatory requirements and supplement with additional sealing or enclosure options if an IP rating is mandated.
Each pack includes one gland plate with T-head punching, one sliding gland plate, and two EMC seals, weighing 1.78 kg per pack. The GTIN is 4028177929869 and the unit is supplied as VX 8618.822. This consistent packaging supports predictable handling and installation planning on site.
