Rittal VX 8620.060 Base Corner Piece - UL 50E Type 1
Part Number: 8620060
Quick Summary
Rittal VX 8620.060 base corner piece provides precise self-positioning for bayed enclosures up to 600 mm wide, enabling reliable front-to-rear alignment. Engineers often contend with misalignment and slow field adjustments; this base corner system eliminates guesswork and shortens installation time while preserving stable baying. The unit carries UL 50E Type 1-rated performance and uses stainless steel 1.4301 (AISI 304) for long-term corrosion resistance in demanding environments. Trim panels and corner covers are included, supporting both configurations with or without trim panels, and the brushed 400 grain finish keeps maintenance effortless. From a procurement perspective, these components simplify spares and enable repeatable enclosure configurations across multiple cabinets.
Product Information
Extended Description
8620060 Rittal: VX Base/plinth corner piece, with base/plinth trim panel, front and rear, H: 200 mm, for W: 600 mm, stainless steel, 1.4301
Article number
VX 8620.060
Product description
Base/plinth corner pieces with moulded self-positioning to the bayed enclosure system, for use with or without trim panels depending on the application. Large openings in the base/plinth corner piece for optimum access to the screw-fastening point may be concealed with a corner and baying cover.
Material
Base/plinth corner piece: Stainless steel 1.4301 (AISI 304) | Base/plinth trim panel front/rear: Stainless steel 1.4301 (AISI 304) | Corner and baying cover: Plastic
Surface finish
Trim panel: Brushed, grain size 400
Supply includes
4 base/plinth corner pieces | 4 corner covers | 1 baying cover | 1 base/plinth trim panel, front/rear, 200 mm high | 2 base/plinth trim panels, front/rear, 100 mm high | Assembly parts
Note
Side base/plinth trim panels finish off a base/plinth unit or provide additional stabilisation between base/plinths or enable interior configuration of the base/plinth
Dimensions
Height: 200 mm
To fit
Width: = 600 mm
Type rating to UL 50E
Type 1
Weight/pack
9.16 kg
Packs of
2 pc(s).
Customs tariff number
94039910
EAN
4028177922334
ETIM 9
EC000721
ECLASS 8.0
27182003
Product description
VX Base/plinth corner piece, with base/plinth trim panel, front and rear, H: 200 mm, for W: 600 mm, stainless steel, 1.4301
Feature: Self-positioning moulded design for bayed enclosures. Benefit: Ensures accurate alignment, reduces rework, and speeds up installation in production cabinets. Application: Ideal for W 600 mm bays in industrial enclosures. Long-tail keyword: bayed enclosure system alignment. Feature: Stainless steel 1.4301 construction for base and trim panels. Benefit: Excellent corrosion resistance and longevity in harsh environments, lowering lifecycle costs. Application: Suitable for factory floors and outdoor-rated enclosures. Long-tail keyword: AISI 304 stainless steel enclosure components. Feature: Front and rear trim panels plus corner and baying covers included. Benefit: Streamlined installation and consistent aesthetics, with reduced parts handling. Application: Converts easily between configurations with or without trim panels. Long-tail keyword: enclosure trim panel compatibility. Feature: Dimensions and UL rating (H 200 mm, W 600 mm, Type 1). Benefit: Non-meticulous fit and verified protection level simplify compliance and cabinet planning. Application: Light-to-medium duty baying installations. Long-tail keyword: UL 50E Type 1 enclosure components. Feature: Supplied as a multi-pack (4 corner pieces, 4 corner covers, 1 baying cover, 2 trim panels). Benefit: Quick replenishment and standardized spares, reducing downtime. Application: OEMs and service teams benefit from predictable inventory. Long-tail keyword: spare parts for base/plinth units. Feature: Brushed trim finish (grain size 400). Benefit: Easy cleaning and professional appearance in cleanroom-adjacent or production environments. Application: Visible enclosures in manufacturing lines. Long-tail keyword: brushed stainless steel trim finish.
Get a Quick Quote for a Rittal 8620060
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8620060?
Enquire Now
FAQs
Begin by aligning the four corner pieces to establish the bay outline, then attach the front/rear trim panels and baying covers as required. The moulded self-positioning design simplifies initial alignment, reducing field adjustments and speeding up commissioning while maintaining a stable base for the enclosure.
Yes. The VX 8620.060 is designed for use with or without trim panels. The kit includes front/rear trim panels and corner covers to support both configurations, enabling flexible interior layouts and straightforward upgrades or reconfigurations.
Base/plinth corner pieces and trim panels are manufactured from stainless steel 1.4301 (AISI 304) for corrosion resistance, with corner covers made of plastic. The trim panels feature a brushed grain finish (grainsize 400) for easy cleaning and a professional appearance in demanding environments.
Yes. The VX 8620.060 carries a UL 50E Type 1 rating, ensuring appropriate protection for electrical enclosures used in standard commercial and industrial settings. This helps meet safety and compliance requirements during system design, installation, and maintenance.
The component set simplifies spare parts management with a standardized pack (four corner pieces, four corner covers, one baying cover, multiple trim panels). This reduces downtime, accelerates installs, and provides repeatable enclosure configurations across multiple bays, delivering measurable reductions in commissioning time and overall maintenance costs.
