Rittal VX 8660.009 Base/Plinth Corner - UL Type 1
Part Number: 8660009
Manufacturer
Rittal
Part number
8660009
Alt Part Number
VX 8660.009
Quick Summary
Rittal VX 8660.009 base/plinth corner pieces deliver stable mounting for VX enclosures in industrial control panels. This accessory simplifies installation and improves the stability of long base/plinth runs, reducing wobble and misalignment during assembly. The UL 50E Type 1 rating provides assurance for light-duty enclosure applications, while ETIM and ECLASS classifications streamline procurement. By pairing robust sheet steel components with front and rear trim panels, these parts support clean cable routing, interior configurability, and scalable cabinet configurations across multiple VX families, delivering measurable efficiency and reliability for panel builders and integrators.
Product Information
Extended Description
8660009 Rittal: VX base/plinth corner piece with trim panel, front and rear, H: 100 mm, for W: 1800 mm, sheet steel
Article number
VX 8660.009
Benefits
Reliable – Excellent stability of the base/plinth
Material
Base/plinth corner piece: Sheet steel | Base/plinth trim panel front/rear: Sheet steel | Corner and baying cover: Plastic
Colour
RAL 9005
Supply includes
4 corner covers | Assembly parts | 4 base/plinth corner pieces, 100 mm high | 2 base/plinth trim panels, front/rear, 100 mm high
Note
Side base/plinth trim panels finish off a base/plinth unit or provide additional stabilisation between base/plinths or enable interior configuration of the base/plinth
Dimensions
Height: 100 mm
To fit
Enclosure type: VX | VX IT | VX SE | TX CableNet | TS | TS IT | TP | PC | IW | CX | Width: = 1,800 mm
Type rating to UL 50E
Type 1
Weight/pack
9.55 kg
Packs of
2 pc(s).
PCF per pack (cradle-to-gate)
36.4 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
94039910
EAN
4028177978102
ETIM 9
EC000721
ETIM 8
EC000721
ECLASS 8.0
27182003
Product description
VX base/plinth corner piece with trim panel, front and rear, H: 100 mm, for W: 1800 mm, sheet steel
Feature → Business Impact → Application: The VX 8660.009 base/plinth corner pieces use durable sheet steel for the base and trim panels, delivering excellent stability and long-term rigidity in VX enclosure installations. This translates to reduced cabinet flex during cable management and high-vibration environments, improving overall system reliability in manufacturing lines and data centers. Application: ideal for VX, VX IT, VX SE, TX CableNet, TS, TS IT, TP, PC, IW, and CX families with a width of 1,800 mm. Feature → Business Impact → Application: Included components—4 corner covers, 4 base/plinth corner pieces, and 2 trim panels—enable quick, drop-in assembly, reducing installation time and labor costs. Application: suitable for quick configuration changes and interior space optimization, supporting iterative designs during machine builds. Feature → Business Impact → Application: Material composition—sheet steel for the main parts and plastic covers for corners—delivers a balanced mix of durability and impact resistance, helping to maintain enclosure integrity under tool changes and frequent reconfigurations. Application: preferred in environments with frequent cabinet re-stacking or interior reconfiguration. Feature → Business Impact → Application: Color coding in RAL 9005 improves visual alignment and corrosion resistance perception, aiding technicians in fast commissioning and maintenance planning. Application: especially beneficial in multi-line facilities where quick identification streamlines service and reduces downtime. Feature → Business Impact → Application: PCF data of 36.4 kg CO2 eq per pack (Cat B) highlights sustainability considerations, supporting green procurement goals and life-cycle assessments. Application: aligns with corporate ESG targets and supplier sustainability programs.
Get a Quick Quote for a Rittal 8660009
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 8660009?
Enquire Now
FAQs
Installation starts with aligning the four base/plinth corner pieces at the enclosure corners and securing the front/rear trim panels. The kit includes four corner covers and assembly parts to simplify attachment, ensuring a square, stable base. This minimizes cabinet wobble and speeds up setup, even in multi-enclosure configurations.
UL Type 1 rating indicates suitability for general indoor use in non-hazardous environments, ensuring basic enclosure integrity for light-duty applications. For VX installations, this supports compliant, safe mounting of components within typical industrial control panels, though higher IP or safety ratings may be required for harsher environments.
VX 8660.009 is designed to fit VX family enclosures with a width of 1,800 mm. It is compatible with VX, VX IT, VX SE, TX CableNet, TS, TS IT, TP, PC, IW, and CX variants, provided the enclosure width matches 1,800 mm. The accessory sits at a 100 mm base height to align with standard VX plinths.
The base/plinth corner pieces are made from sheet steel for durability, with sheet steel trim panels on the front and rear, and plastic corner/baying covers. The finish is RAL 9005 black, providing corrosion resistance and a uniform appearance across the base of the enclosure lineup.
Yes. Each pack has a PCF of 36.4 kg CO2 equivalent (Category B), reflecting its cradle-to-gate environmental footprint. This data supports sustainability reporting and green procurement. Coupled with faster installation and improved stability, the accessory can reduce installation time and post-install downtime, boosting overall return on investment.
