Rittal AX 9207.100 Ex Enclosure - ATEX/IEC Ex Certified
Part Number: 9207100
Quick Summary
Rittal AX 9207.100 Ex Enclosure is a rugged housing for hazardous-location control panels. Engineers often struggle with ingress, corrosion, and meeting complex explosion-protection standards in challenging sites. This enclosure carries IEC Ex PTB 10.0011U and PTB 03 ATEX 1011U approvals, supports IP65 protection with a robust gasket seal, and features IK09 impact resistance for tough environments. With mounting plate inclusion and a design optimized for quick, compliant installation, it delivers reliable protection while minimizing maintenance and downtime. In practice, it enables safer panel deployment, reduces risk, and supports efficient integration with standard mounting components and a broad range of automation hardware.
Product Information
Extended Description
9207100 Rittal: AX Ex enclosure, WHD: 500x500x300 mm, fibreglass-reinforced unsaturated polyester, with mounting plate, empty enclosure with hinged door
Article number
AX 9207.100
Design
Ex enclosures
Material
Fibre-glass-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω | Door: Fibreglass-reinforced unsaturated polyester, surface resistance: < 10⁹ Ω, bonded all-round silicone seal | Mounting plate: Sheet steel, zinc-plated
Colour
RAL 9011
Supply includes
Enclosure | Door | Mounting plate
Dimensions
Width: 500 mm | Height: 500 mm | Depth: 300 mm
Dimensions mounting plate (W x H)
405 mm x 425 mm
Material thickness of mounting plate
3 mm
Certificate IEC EX PTB 10.0011U
Yes
Certificate PTB 03 ATEX 1011U
Yes
Lock
Number of locks: 2
IP protection category to IEC 60 529
IP 65
Protection category NEMA
Type 1
IK Code
IK09
Packs of
1 pc(s).
Weight/pack
14.8 kg
PCF per pack (cradle-to-gate)
74.4 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
94037000
EAN
4028177952119
ETIM 9
EC002503
ECLASS 8.0
27180502
Product description
AX Ex enclosure, WHD: 500x500x300 mm, fibreglass-reinforced unsaturated polyester, with mounting plate, empty enclosure with hinged door
Feature: Fibreglass-reinforced unsaturated polyester construction provides excellent chemical and weather resistance. Benefit: Extends service life in harsh environments and lowers replacement costs, especially for outdoor or damp locations. Application: Ideal for process automation cabinets exposed to dust, moisture, or chemical exposure. Feature: IP65 protection and bonded silicone seal for all-round enclosure sealing. Benefit: Keeps electronics safe from ingress and reduces costly field failures, boosting uptime. Application: Critical in outdoor substations or outdoor control panels. Feature: Dimensions 500x500x300 mm with mounting plate 405x425 mm (3 mm thick). Benefit: Offers ample internal space while allowing a compact footprint and compatibility with common mounting patterns. Application: Quick-mix installations in existing rack layouts. Feature: Door hinged, two locks, and gasket performance. Benefit: Improves security and tamper resistance with straightforward access control. Application: Hazardous-location control panels requiring protection against unauthorized access. Feature: Material and surface properties include < 10^9 Ω surface resistance and bonded mounting plate; weight 14.8 kg per pack. Benefit: Static-safe enclosure suitable for electronics handling and straightforward handling during installation. Application: Equipment cabinets in electronics-intensive environments. Feature: Certifications IEC Ex PTB 10.0011U and PTB 03 ATEX 1011U. Benefit: Regulatory compliance for explosive atmospheres, reducing certification cycles and project risk. Application: Ex-protection projects in chemical, oil, and gas sectors. Feature: Supply includes enclosure, door, and mounting plate. Benefit: Ready-to-install package minimizes sourcing steps and accelerates project timelines. Application: Customer deployments requiring fast, compliant cabinet assembly.
Get a Quick Quote for a Rittal 9207100
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9207100?
Enquire Now
FAQs
The AX 9207.100 includes a mounting plate measuring 405 x 425 mm with a 3 mm thickness, designed to fit common enclosure footprints. It ships as a ready-to-install package with enclosure, door, and mounting plate, simplifying integration into standard control cabinets and reducing on-site customization.
Key specs include a 500 x 500 x 300 mm exterior footprint, FRP material with surface resistance < 10^9 Ω, IP65 protection, IK09 impact rating, two locking points, and a bonded silicone seal. Weight per pack is 14.8 kg, and the enclosure is supplied with mounting plate, door, and enclosure body.
Yes. It carries IEC Ex PTB 10.0011U and PTB 03 ATEX 1011U certifications, indicating compliance for explosion-protected environments. It also offers IP65 protection and IK09 impact resistance, making it suitable for hazardous locations in chemical, oil, and gas industries, as well as outdoor installations.
Utilize the bonded all-round silicone seal and gasketed hinged door to maintain ingress protection. FRP construction offers corrosion resistance in harsh environments, while the mounting plate and steel hardware provide a robust mechanical interface. Regular inspection for seal integrity and periodic cleaning with non-abrasive cleaners help preserve performance and prolong life in tough sites.
Although upfront costs reflect high-specification protection, the AX 9207.100 delivers lower maintenance spend due to corrosion resistance, fewer field faults, and faster commissioning thanks to ready-to-install packaging. Coupled with compliance-driven risk reduction from IEC Ex and ATEX certifications, this enclosure supports longer service intervals and improved uptime in hazardous environments.
