Rittal 9340224 SV Support panel - UL 94-V0 rated
Part Number: 9340224
Manufacturer
Rittal
Part number
9340224
Category
Alt Part Number
SV 9340.224
Quick Summary
Rittal SV 9340.224 SV support panel is designed to increase enclosure stability and prevent side access to the cover. Engineers and technicians often battle cover misalignment and inadvertent openings that degrade safety and complicate maintenance. Built with UL 94-V0 rated polyamide and aligned with ETIM EC000775 and ECLASS 27142414 classifications, it supports regulatory compliance and easy sourcing. With 4-pole busbar compatibility and a RAL 7035 finish, installation is straightforward and cabinet layouts remain consistent. This accessory delivers tangible business value by reducing field adjustments, enhancing safety, and accelerating assembly in production and service environments.
Product Information
Extended Description
9340224 Rittal: SV Support panel, for cover section, SV 9340214
Article number
SV 9340.224
Product description
To prevent side access to the cover section. The support panel also provides additional stability. Recommended mounting distance ≤ 500 mm.
Material
Polyamide | Fire protection corresponding to UL 94-V0
Colour
RAL 7035
To fit busbar system
4-pole
Packs of
5 pc(s).
Weight/pack
0.19 kg
Customs tariff number
39269097
EAN
4028177536753
ETIM 9
EC000775
ECLASS 8.0
27142414
Product description
SV Support panel, for cover section, SV 9340214
Feature: UL 94-V0 polyamide material provides innate flame retardancy and non-conductive safety, which translates to improved compliance during audits and safer cabinet environments. Business impact: reduces risk of internal arcing and simplifies safety documentation; Application: ideal for control cabinets and power distribution enclosures where proximity to live components is a concern. Feature: Prevents side access to the cover section, increasing tamper resistance and shielding sensitive busbar connections. Business impact: lowers maintenance rework and protects operators; Application: high-density panels and service points in industrial automation lines. Feature: 4-pole busbar system compatibility ensures a reliable fit with common busbar configurations. Business impact: minimizes installation time and error-prone custom adaptions; Application: SV 9340214 cover assemblies and similar enclosures. Feature: Packs of 5 pieces with a weight of 0.19 kg per pack enable scalable stocking and efficient logistics. Business impact: reduces inventory fragmentation; Application: procurement across multiple control cabinets. Feature: RAL 7035 color coding aids rapid visual identification and cabinet standardization. Business impact: speeds wiring and maintenance tasks; Application: large-scale panel ecosystems. Feature: Defined mounting distance ≤ 500 mm supports predictable rigidity and service access. Business impact: improves enclosure stability and reduces vibration-related wear; Application: dense cabinet installations in manufacturing cells and data centers.
Get a Quick Quote for a Rittal 9340224
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9340224?
Enquire Now
FAQs
The SV 9340224 is designed to fit 4-pole busbar configurations, ensuring a secure, stable interface with common busbar systems. It supports straightforward mounting on SV 9340214 cover assemblies and helps maintain consistent electrical clearances. This compatibility minimizes modification requirements and speeds up panel integration in control cabinets.
The panel uses UL 94-V0 rated polyamide, providing flame retardancy and non-conductive protection. By preventing side access to the cover section, it reduces the risk of accidental contact with live parts, enhances operator safety, and lowers maintenance-related exposure in crowded enclosures.
Yes, it is designed for straightforward installation on SV cover assemblies with a recommended mounting distance of 500 mm or less. This spacing promotes rigidity, reduces vibration, and simplifies service access, making installation predictable and repeatable across multiple cabinets.
The product uses UL 94-V0 rated polyamide, a widely accepted fire protection standard for enclosure components. It also aligns with ETIM EC000775 and ECLASS 27142414 classifications, supporting standardized procurement and consistent documentation across supplier catalogs.
By increasing enclosure stability and preventing cover-side access, the panel reduces misalignment, minimizes maintenance retries, and speeds routine servicing. The standardized 5-pack and lightweight design simplify stocking, while the 4-pole busbar compatibility minimizes changeovers and improves overall reliability in production environments.
