Rittal 9340.760 SV OM adaptor - UL 30 kA SCCR
Part Number: 9340760
Manufacturer
Rittal
Part number
9340760
Category
Alt Part Number
SV 9340.760
Quick Summary
SV OM adaptor for 690 V, 3-pole power distribution in enclosures. Engineers rely on safe, UL-rated wiring inside compact control cabinets, and this adaptor delivers a robust solution. This part features UL SCCR ratings up to 30 kA at 600 V and a fire-retardant polyamide body (UL94-V0), plus TS 45D rail compatibility. It supports fast, compliant assembly with a 60 mm busbar center-to-center spacing and a 165 mm connection cable. Designed for easy mounting with a PinBlock and a dedicated support frame, it accelerates panel builds and serviceability. Typical applications include machine control panels, industrial automation cabinets, and modular power distribution blocks, delivering reliable power interfaces in demanding environments.
Product Information
Extended Description
9340760 Rittal: SV OM adaptor, 16 A, 690 V, 3-pole, connection cable AWG 12, WH: 45x272 mm, support frame, PinBlock, support rail TS 45D
Article number
SV 9340.760
Material
Polyamide | Fire protection corresponding to UL 94-V0
Colour
Chassis: RAL 7035
Connection cables (AWG)
AWG 12
Rated current max.
16 A
Rated operating voltage
690 V, 3~
Electrical ratings UL (SCCR)
30 kA - 600 V, Fuse Class K5 max. 60 A, JDDZ/7
For bar systems with centre-to-centre spacing
60 mm
Length of connection cable
165 mm
Support rail type
TS 45D
Note
The technical data may vary for UL applications
Number of poles
3-pole
PinBlock
Yes
Support frame support
Yes
Dimensions
Width: 45 mm | Height: 272 mm
Support rails Qty/height
1 / 10 mm
To fit busbars
Height: 5, 10 mm
Support frame (W x H)
45 mm x 237 mm
Packs of
1 pc(s).
Weight/pack
0.305 kg
Copper weight (kg per piece)
0.038
Customs tariff number
85369095
EAN
4028177684553
ETIM 9
EC001531
ECLASS 8.0
27370304
Product description
SV OM adaptor, 16 A, 690 V, 3-pole, connection cable AWG 12, WH: 45x272 mm, support frame, PinBlock, support rail TS 45D
SV OM adaptor combines high-quality materials with practical design to deliver measurable business outcomes. Feature: 16 A current rating and 690 V operating voltage provide a single, standards-aligned solution for medium-power distribution; Business Impact: reduces the need for multiple adapters and simplifies warranty-compliant wiring; Application: ideal for enclosure power feeds in automation panels. Feature: 3-pole configuration with AWG 12 connection cables enables straightforward, code-compliant wiring; Business Impact: lowers installation time and wiring errors while improving fault tracing; Application: supports clean, modular panel builds. Feature: UL SCCR 30 kA at 600 V and Fuse Class K5 compatibility enhance short-circuit protection; Business Impact: strengthens safety margins and minimizes fuse management costs; Application: suitable for critical distribution rails in control cabinets. Feature: TS 45D rail compatibility and 60 mm center-to-center busbar spacing simplify physical fitment; Business Impact: reduces mounting complexity and stock diversity; Application: ensures quick retrofits alongside existing busbar systems. Feature: Fire-retardant Polyamide with UL94-V0 rating improves enclosure safety; Business Impact: mitigates risk in harsh environments and supports compliance efforts; Application: suitable for demanding industrial environments. Feature: Included PinBlock and dedicated support frame speed alignment and install accuracy; Business Impact: lowers rework and service time; Application: accelerates commissioning of modular equipment in machine lines.
Get a Quick Quote for a Rittal 9340760
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9340760?
Enquire Now
FAQs
Begin by confirming rail compatibility and space. Affix the adaptor's support frame to the TS 45D rail, align the PinBlock, then secure the 3-pole module using the integrated mounting provisions. Connect the AWG12 cables to the busbars at the designated 60 mm center-to-center spacing, and verify the 165 mm connection length is accommodated within the enclosure to ensure proper clearance and cooling.
The adaptor supports up to 16 A nominal current and 690 V operating voltage, configured as 3-pole with a 165 mm connection cable. It provides UL SCCR protection up to 30 kA at 600 V and is compatible with Fuse Class K5 up to 60 A. Material is fire-retardant polyamide with UL94-V0 rating, suitable for safe panel integration.
Yes. It fits standard TS 45D rails and utilizes a 60 mm center-to-center spacing for busbars, with a 165 mm connection cable length. The product includes a PinBlock and a support frame to ensure precise alignment and secure mounting, making it compatible with common Rittal enclosure and busbar configurations.
The SV OM adaptor features UL SCCR ratings of up to 30 kA at 600 V and uses UL94‑V0 fire-retardant polyamide. It is designed for safe integration into control cabinets and distribution blocks, with notes indicating UL data may vary for UL applications. Compliance is reinforced by the TS 45D rail compatibility and 60 mm busbar spacing.
The adaptor reduces wiring time and installation complexity through a combined frame, PinBlock, and rail-ready design, lowering commissioning costs. Its robust polyamide body and UL-rated protections minimize maintenance needs, while the modular 3-pole configuration supports scalable panel designs and easier future upgrades in automation environments.
