Rittal 9345704 SV Circuit-breaker adaptor - UL 94-V0
Part Number: 9345704
Manufacturer
Rittal
Part number
9345704
Category
Alt Part Number
SV 9345.704
Quick Summary
SV circuit-breaker adaptor enables safe, high-current interconnection for ABB switchgear. For engineers, mismatched interfaces and material ratings can slow commissioning and introduce risk. This adaptor leverages UL 94‑V0 fire protection and a 690 V operating voltage with a 500 A rated current to meet stringent safety and performance requirements. By matching 60 mm center-to-center busbar spacing and offering bottom cable outlet, it simplifies installation and reduces field modification costs. The included copper spacer roll, connection screws, and contact plates streamline assembly while maintaining robust electrical contact. Built for Rittal’s power management ecosystem, the part integrates smoothly with Tmax T5 configurations and other 4-pole switchgear interfaces, delivering reliable, scalable protection.
Product Information
Extended Description
9345704 Rittal: SV Circuit-breaker component adaptor, 500 A, 690 V, 4-pole, cable outlet bottom, for switchgear make:, ABB
Article number
SV 9345.704
Material
Polyamide | Fire protection corresponding to UL 94-V0
Colour
RAL 7035
Supply includes
Copper spacer roll | Connection screws | Contact plates
Rated current max.
500 A
Rated operating voltage
690 V, 4~
Cable outlet
Bottom
For bar systems with centre-to-centre spacing
60 mm
Note
Cable outlet: Switch outlet or as outgoing cable from the switchgear
Number of poles
4-pole
Dimensions
Width: 185 mm | Height: 300 mm
To fit busbars
Height: 5, 10 mm
To fit manufacturer (model)
ABB (Tmax T5)
Packs of
1 pc(s).
Weight/pack
4.027 kg
Copper weight (kg per piece)
2.765
Customs tariff number
85369095
EAN
4028177684515
ETIM 9
EC001531
ECLASS 8.0
27370304
Product description
SV Circuit-breaker component adaptor, 500 A, 690 V, 4-pole, cable outlet bottom, for switchgear make:, ABB
Feature: High-current capacity up to 500 A. Business impact: Enables safe, reliable power distribution in high-demand ABB Tmax T5 configurations, reducing downtime during upgrades. Application: Ideal for 4-pole assemblies in industrial switchgear where robust current handling is essential. Feature: Bottom cable outlet and 60 mm center-to-center spacing. Business impact: Streamlines cabling topology and simplifies panel layout, cutting wiring time and error rates. Application: Suitable for compact panel designs in power management and distribution solutions. Feature: Polyamide housing with UL 94-V0 fire protection. Business impact: Enhances fire safety compliance and mechanical durability in harsh environments, lowering risk of containment faults. Application: Preferred for control cabinets and switchgear housings. Feature: Supplied components—copper spacer roll, connection screws, contact plates. Business impact: Reduces on-site scavenging of hardware, accelerates installation, and ensures repeatable, solid electrical connections. Application: Fast-track retrofits and new builds in automation environments. Feature: Compatibility with ABB Tmax T5 and 60 mm busbar layouts. Business impact: Simplifies sourcing and engineering workflows by providing a standardized adaptor for common switchgear. Application: Widely used in industrial automation and power distribution projects.
