Rittal 9350010 Busbar Cover Section - UL 94-V0
Part Number: 9350010
Manufacturer
Rittal
Part number
9350010
Category
Alt Part Number
SV 9350.010
Quick Summary
Rittal 9350010 Busbar Cover Section provides all-round encapsulation of busbars for safe enclosure in switchgear and control cabinets. However, maintenance teams face contact hazards when busbars are exposed; this cover mitigates risk and simplifies safety compliance. The design uses thermally modified hard PVC with UL 94-V0 fire protection, and the finish aligns with European cabinet practices, supporting CE-driven installations. Its RAL 7035 color ensures clear visibility and standardization across assemblies, while the modular length supports efficient stocking and streamlined procurement for engineers and buyers. This accessory adds business value by improving safety, reducing rework, and helping organizations meet regulatory expectations without causing schedule delays.
Product Information
Extended Description
9350010 Rittal: SV Busbar cover section, for demension WH: 12/15x5 mm, L: 1000 mm/section
Article number
SV 9350.010
Product description
Contact hazard protection by covering the busbars.
Material
Thermally modified hard PVC. | Fire protection corresponding to UL 94-V0
Colour
RAL 7035
Length
1,000 mm
Note
May be cut individually to required length
To fit busbars
Busbar E-Cu
To fit busbars
12/15 x 5 mm
Packs of
4 pc(s).
Weight/pack
0.42 kg
Customs tariff number
85472000
EAN
4028177219557
ETIM 9
EC000775
ECLASS 8.0
27142414
Product description
SV Busbar cover section, for demension WH: 12/15x5 mm, L: 1000 mm/section
UL 94-V0 thermally modified hard PVC provides reliable contact hazard protection. This material choice elevates enclosure safety, reduces the risk of arcing and surface burns, and supports ongoing compliance with fire-safety standards in electrical panel environments. In switchgear and control cabinets, users benefit from a protective barrier that remains intact under normal service temperatures and minor mechanical abuse. Length of 1,000 mm per section offers practical flexibility and can be cut to the required length, reducing waste and inventory complexity while accelerating on-site installation. The cover is designed to fit 12/15 x 5 mm busbars and E-Cu copper busbars, enabling broad compatibility with common power distribution architectures. Its color, RAL 7035, supports standardized visual cues for safety and maintenance workflows across multiple cabinets. Pack configurations of four pieces per pack and a weight of 0.42 kg per pack facilitate efficient warehousing, shipping, and handling in busy electrical rooms.
Get a Quick Quote for a Rittal 9350010
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9350010?
Enquire Now
FAQs
Install the 9350010 cover by aligning the 12/15 x 5 mm busbar interface with the busbars inside the cabinet. Cut the 1,000 mm length to the required section, then snap or fasten the cover to the enclosure edges as per the cabinet manufacturer's guidelines. Ensure the cover fully encloses exposed busbars to eliminate touch hazards and verify the fit against the E-Cu busbar geometry.
Yes. The cover is specified to fit busbars 12/15 x 5 mm and is designed to accommodate E-Cu copper busbars, providing a reliable physical shield without restricting electrical connections or ventilation. This compatibility supports common European power distribution designs in control panels and switchgear.
The material achieves UL 94‑V0 fire protection, indicating flame retardancy for safety-critical enclosure components. While CE conformity is typical for European installations, always verify local certification requirements and consult the datasheet for installation guidelines and compliance mappings to your project standards.
Benefits include improved operator safety by preventing direct contact with live busbars, enhanced regulatory compliance through fire-safety-rated material, and installation efficiency from a cut-to-length design. The standard RAL 7035 finish supports consistent aesthetics across cabinets, aiding maintenance workflows and reducing misidentification during servicing.
Each pack contains four busbar cover sections, with a total weight of 0.42 kg per pack. This packaging supports straightforward warehousing, efficient shipping, and predictable inventory management for project teams and distributors.
