Rittal SV 9393.561 Output Module - EN 61869-1/2
Part Number: 9393561
Manufacturer
Rittal
Part number
9393561
Category
Alt Part Number
SV 9393.561
Quick Summary
Rittal SV 9393.561 is a compact busbar mounting module designed for safe, high-current power distribution in control cabinets. In practice, engineers face space constraints and complex wiring that slow installation and raise risk of faults. It meets EN 61869-1/2 and UL 94 fire protection standards, delivering reliable performance across -5 to 55 °C and 10–90% humidity. The product’s robust polyamide housing supports long life in demanding environments, while the included mounting hardware reduces assembly time and total cost of ownership. For procurement teams, its standardized design strengthens compatibility with Rittal enclosures and broader power-management strategies, supporting efficient, compliant cabinet builds and scalable installations.
Product Information
Article number
SV 9393.561
Design
Output voltage 333 mV
Material
Polyamide | Fire protection corresponding to UL 94
Colour
RAL 9005
Supply includes
2 plug-in feet | 2 insulating caps | 1 primary bar clamp | 2 grub screws
To fit busbars
null mm
Primary current
800 A
Standards
EN 61869-1/ 2
Dimensions
Width: 85 mm | Height: 108 mm | Depth: 30 mm
Operating temperature range
-5 °C...55 °C
Storage temperature range
-25 °C...75 °C
Ambient humidity (non-condensing)
10...90 %
Connection for round conductor
0.5 ‐ 2.5 mm²
Fundamental frequency
50...60 Hz
Accuracy Class
0.5
Insuslation material (class)
F
Packs of
1 pc(s).
Customs tariff number
85043129
EAN
4028177049383
Feature: Compact dimensions (Width 85 mm, Height 108 mm, Depth 30 mm) -> Business Impact: Enables dense panel layouts with retaining mechanical robustness -> Application: Ideal for space-constrained control cabinets and switchgear assemblies. Feature: High primary current rating (800 A) -> Business Impact: Supports heavy power distribution without frequent upgrades -> Application: Feeds high-current circuits in industrial automation panels. Feature: Material and safety (Polyamide; UL 94 fire protection) -> Business Impact: Improves safety and regulatory compliance while reducing material risks -> Application: Suitable for environments requiring flame retardant housing and durable insulation. Feature: Mounting hardware included (2 plug-in feet, 2 insulating caps, 1 primary bar clamp, 2 grub screws) -> Business Impact: Accelerates installation and enhances vibration resistance -> Application: Quick, reliable integration into existing busbar assemblies. Feature: Electrical specifications (Output voltage 333 mV; 50–60 Hz; 0.5–2.5 mm² conductor connection) -> Business Impact: Delivers consistent measurement and connection quality across standard mains and control circuits -> Application: Fits typical automation and power management schemes. Feature: Safety and compliance (EN 61869-1/2; operating -5 to 55 °C; storage -25 to 75 °C; humidity 10–90%) -> Business Impact: Reduces risk of non-compliance and unscheduled downtime by operating reliably in varying environments -> Application: Suitable for global deployments with diverse climate conditions. Feature: Dimensional and labeling clarity (Dimensions and EAN provided) -> Business Impact: Improves traceability and stocking accuracy -> Application: Streamlines procurement, inventory control, and maintenance planning.
Get a Quick Quote for a Rittal 9393561
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9393561?
Enquire Now
FAQs
SV 9393.561 is designed for robust integration in Rittal control cabinets. It offers a compact footprint (85 x 108 x 30 mm) and accepts round conductors in the 0.5–2.5 mm² range, supported by two plug-in feet, insulating caps, a primary bar clamp, and grub screws for secure mounting. The hardware set simplifies alignment and vibration resistance, enabling reliable, repeatable installations across common enclosure types.
Key specs include an output voltage of 333 mV, a primary current rating of 800 A, and a fundamental frequency of 50–60 Hz. The device operates from -5 to 55 °C and stores from -25 to 75 °C, with ambient humidity tolerance of 10–90% non-condensing. The insulation class is F, supporting safe operation in typical automation environments.
Yes. SV 9393.561 complies with EN 61869-1/2 for electrical measuring and current distribution components and uses a UL 94 flame-retardant polyamide housing. These certifications help ensure regulatory compliance, fire safety, and dependable performance in industrial power management applications.
The package includes 2 plug-in feet, 2 insulating caps, 1 primary bar clamp, and 2 grub screws. This hardware set supports quick, secure mounting to busbars, improves vibration resistance, and reduces assembly steps, which together shorten deployment time in new builds or retrofits and simplify field service.
By delivering high-current distribution in a compact form factor with UL and EN certifications, SV 9393.561 reduces panel size and wiring complexity, lowers maintenance risk, and improves uptime. Its durable materials and included mount hardware streamline installation, supporting scalable power management strategies across manufacturing environments.
