Rittal 9393563 Power Module - EN 61869-1/2 Certified
Part Number: 9393563
Manufacturer
Rittal
Part number
9393563
Category
Alt Part Number
SV 9393.563
Quick Summary
Rittal 9393563 Power Module is a compact busbar‑side measurement and distribution unit designed for control panels. Engineers face challenges with safe insulation, space constraints, and accurate current measurement in high‑current assemblies, and this module addresses those pain points with a compact footprint and reliable performance. This product meets EN 61869-1/2 standards and uses UL 94 fire‑rated polyamide, supporting safe operation in demanding environments. In daily procurement and maintenance, it translates to fewer part numbers and faster commissioning in control cabinets and switchgear. The design also supports plug‑in feet and prescribed mounting hardware for simplified installation, making it a future‑proof choice for high‑demand electrical assemblies.
Product Information
Article number
SV 9393.563
Design
Output voltage 333 mV
Material
Polyamide | Fire protection corresponding to UL 94
Colour
RAL 9005
Supply includes
2 plug-in feet | 2 insulating caps | 1 primary bar clamp | 2 grub screws
To fit busbars
null mm
Primary current
1,000 A
Standards
EN 61869-1/ 2
Dimensions
Width: 85 mm | Height: 108 mm | Depth: 30 mm
Operating temperature range
-5 °C...55 °C
Storage temperature range
-25 °C...75 °C
Ambient humidity (non-condensing)
10...90 %
Connection for round conductor
0.5 ‐ 2.5 mm²
Fundamental frequency
50...60 Hz
Accuracy Class
0.5
Insuslation material (class)
F
Packs of
1 pc(s).
Customs tariff number
85043129
EAN
4028177049482
Feature: 1,000 A primary current design. Business impact: Enables reliable high‑current distribution without excessive enclosure size. Application: Suitable for switchgear, power distribution boards, and heavy‑duty control cabinets. The result is improved space efficiency and reduced thermal stress in dense panel layouts. Feature: EN 61869‑1/2 compliance. Business impact: Ensures accurate current measurement and interoperability with standard test and protection schemes. Application: Ideal for metering points and protection schemes in power management assemblies. Feature: UL 94 fire‑rated polyamide housing. Business impact: Enhanced safety and fire resistance, lowering risk in cabinet environments. Application: Used in enclosures and wiring routes where flame retardance matters. Feature: Compact dimensions (Width 85 mm, Height 108 mm, Depth 30 mm) with plug‑in feet and included insulating caps. Business impact: Quick, tool‑free mounting reduces installation time and commissioning costs. Application: Fits tight panel cavities and allows rapid replacement during maintenance. Feature: Mounting hardware and connection options (2 plug‑in feet, 2 insulating caps, 1 primary bar clamp, 2 grub screws). Business impact: Streamlines installation and ensures secure, vibration‑resistant connections. Application: Optimizes integration in busbar systems and modular switchgear. Feature: Broad environmental range (−5 °C to 55 °C; 10–90% RH non‑condensing). Business impact: Reliable operation across factory floors and varying ambient conditions. Application: Suitable for industrial environments without additional enclosure heating or cooling. Feature: 0.5 A‑to‑2.5 mm² round conductor connection; 50–60 Hz operation; 0.5 precision class; F insulation class. Business impact: Supports precise, stable measurement with broad compatibility. Application: Common in modern electrical panels and distribution blocks, enabling consistent performance across installations.
