Rittal SV 9393.572 Busbar Adapter - EN 61869-1/2
Part Number: 9393572
Manufacturer
Rittal
Part number
9393572
Category
Alt Part Number
SV 9393.572
Quick Summary
SV 9393.572 is a busbar adapter that enables mounting and measurement in industrial power distribution enclosures. Engineers often struggle with misaligned busbars, unreliable clamp connections, and maintaining measurement accuracy during panel assembly. Designed to EN 61869-1/2 and built with UL 94 fire-rated polyamide, it offers safe operation across most shop floors and field environments. The rugged construction and included plug-in feet simplify installation, while the 2,500 A primary current rating and 50–60 Hz compatibility support scalable, precise sensing in modern switchgear. For value-focused teams, this accessory reduces commissioning time and supports compliant, repeatable busbar mounting in growing power systems.
Product Information
Article number
SV 9393.572
Design
Output voltage 333 mV
Material
Polyamide | Fire protection corresponding to UL 94
Colour
RAL 9005
Supply includes
2 plug-in feet | 4 insulating caps | 2 primary bar clamps | 4 grub screws
To fit busbars
null mm
Primary current
2,500 A
Standards
EN 61869-1/ 2
Dimensions
Width: 129 mm | Height: 156 mm | Depth: 30 mm
Operating temperature range
-5 °C...55 °C
Storage temperature range
-25 °C...75 °C
Ambient humidity (non-condensing)
10...90 %
Connection for round conductor
0.5 ‐ 2.5 mm²
Fundamental frequency
50...60 Hz
Accuracy Class
0.5
Insuslation material (class)
F
Packs of
1 pc(s).
Customs tariff number
85043129
EAN
4028177049925
Feature: 333 mV output enables direct connection to low-voltage sensing circuits; Business impact: streamlines signal routing and improves measurement accuracy; Application: ideal for current sensing in switchgear and panel boards. Feature: Compact footprint with dimensions 129 mm wide, 156 mm high, 30 mm deep; Business: simplifies layout planning and reduces enclosure size requirements; Application: ideal in compact power distribution cabinets. Feature: Supplied with 2 plug-in feet, 4 insulating caps, 2 primary bar clamps, and 4 grub screws; Business: accelerates assembly and minimizes missing parts risk; Application: fast retrofit or new installations. Feature: Primary current rating up to 2,500 A with EN 61869-1/2 compliance and insulation class F; Business: ensures accuracy under high current and safe operation; Application: high-current distribution panels. Feature: Environmental and electrical specs include -5 to 55 °C operating range, -25 to 75 °C storage, 10–90% humidity, 0.5–2.5 mm² conductor connection, and 50–60 Hz; Business: ensures reliable operation across typical industrial climates; Application: suited to general purpose switchgear.
Get a Quick Quote for a Rittal 9393572
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9393572?
Enquire Now
FAQs
Begin by confirming conductor contact range of 0.5–2.5 mm² and ensuring enclosure compatibility. Mount the adapter using the included plug-in feet and mounting clamps, then secure with the four grub screws as specified. Verify busbar alignment, tighten all fasteners to recommended torque, and connect sensing leads to minimize electrical noise. The standardized dimensions help preserve enclosure clearance and allow tidy routing of cables.
The adapter provides a 333 mV output and supports a primary current rating up to 2,500 A. It operates at 50–60 Hz and features an insulation class F with UL 94 fire protection. The accuracy class is 0.5, enabling precise current sensing in power distribution panels, while the conductor connection range is 0.5–2.5 mm².
Yes. With a primary current rating of 2,500 A and EN 61869-1/2 compliance, the adapter is designed for demanding switchgear environments. Its rugged polyamide body and UL 94 fire rating contribute to safe operation, while the compact 129 × 156 × 30 mm footprint supports straightforward integration into standard enclosures.
SV 9393.572 complies with EN 61869-1/2 for protective-current measurement accessories and uses UL 94 certified polyamide for flame retardancy. Its materials and construction are chosen to support safe operation within typical industrial temperatures (-5 to 55 °C) and humidity (10–90%), aligning with common electrical safety practices in power distribution.
The accessory reduces installation time through plug-in feet, clamps, and included fasteners, decreasing field labor and potential part omissions. Its high-current capacity and precise 333 mV output lower commissioning risk, while EN 61869-1/2 compliance supports regulatory documentation and long-term reliability in power distribution systems.
