Rittal 9629000 SV Mini-PLS component adaptor - UL94-V0
Part Number: 9629000
Manufacturer
Rittal
Part number
9629000
Category
Alt Part Number
SV 9629.000
Quick Summary
Rittal SV Mini-PLS component adaptor is a high-current distribution solution designed for 690 V panel systems. Engineers often contend with space constraints, wiring complexity, and safety compliance in modern control cabinets. This adaptor features UL 94‑V0 fire protection, a 690 V rating, and a 100 A max, aligning with rigorous panel standards. In addition, its compact footprint and 3‑pole design support efficient layouts and faster builds, while broad compatibility with ABB, Eaton, Schneider Electric, and Siemens models helps streamline procurement across projects.
Product Information
Extended Description
9629000 Rittal: SV Mini-PLS component adaptor, 100 A, 690 V, 3-pole, connection cable 35 mm², WH: 90x160 mm
Article number
SV 9629.000
Material
Polyamide | Fire protection corresponding to UL 94-V0
Colour
RAL 9011
Connection cables (AWG)
35 mm²
Rated operating voltage
690 V, 3~
Rated current max.
100 A
Dimensions
Width: 90 mm | Height: 160 mm
To fit manufacturer (model)
ABB | Eaton | Schneider Electric | Siemens | MS451 max. 40 A | MS495 | MS496 | MS497 | T1 | T2 | NZM 1 | PKZM4 | NS 80 | GV3 | 3RV10 31 | 3RV1341/42
Packs of
1 pc(s).
Weight/pack
0.794 kg
Copper weight (kg per piece)
0.23
Customs tariff number
85369095
EAN
4028177149861
ETIM 9
EC001531
ECLASS 8.0
27370304
Product description
SV Mini-PLS component adaptor, 100 A, 690 V, 3-pole, connection cable 35 mm², WH: 90x160 mm
The SV Mini-PLS adaptor supports up to 100 A at 690 V in a compact 3‑pole module, using 35 mm² cables. This enables engineers to consolidate power distribution within tight panel footprints, reducing wiring complexity and potential contact resistance in critical feeds. It’s ideal for panel builders and machine builders needing reliable, heavy-gauge connections without expanding enclosure size. Material and safety are addressed with polyamide housing and UL 94‑V0 fire protection, boosting cabinet safety and helping meet safety standards while maintaining insulating performance. Compatibility is enhanced by a 90x160 mm footprint that fits typical Rittal enclosures and supports connections to ABB, Eaton, Schneider Electric, Siemens; packaging of 1 piece enables simple procurement and inventory control. Reliability is reinforced by the copper weight per piece of 0.23 kg, ensuring durable current paths and predictable thermal behavior over the product lifecycle, reducing maintenance costs and downtime.
