Rittal 9635010 SV Board - UL 508 125 A Rated Busbar
Part Number: 9635010
Manufacturer
Rittal
Part number
9635010
Category
Alt Part Number
SV 9635.010
Quick Summary
The Rittal SV Board 9635010 is a shock-hazard protected busbar board designed for safe component mounting in control panels and distributed power assemblies. Engineers often struggle with safe wiring access and space constraints; this board enables quick, plug-in mounting with integrated busbars, reducing installation risk and time. It complies with UL 508, UL 94 fire protection and IP20 protection, providing regulatory confidence for European and North American control panels. Designed for mounting on support rails and mounting plates, SV 9635.010 supports rapid assembly, easy scalability, and reliable operation in harsh industrial environments. In practice, this translates to lower total cost of ownership through simplified wiring, faster commissioning, and improved fault isolation in power distribution applications across installations.
Product Information
Extended Description
9635010 Rittal: SV Board, 125 A, 690 V (AC). 600 V (DC), 3-pole, WHD: 405x160x45,1 mm
Article number
SV 9635.010
Function principle
Shock-hazard-protected busbar board for the safe accommodation and contacting of components, thanks to simple plug-in mounting
Material
Polyamide | Polycarbonate | E-Cu | Fire protection corresponding to UL 94
Colour
RAL 7035
Supply includes
Integral busbars
IP protection category to IEC 60 529
IP 20
Standards
UL 508
Rated current max.
125 A
Rated current (UL)
100 A
Rated operating voltage
690 V (AC)
Rated operating voltage (max.) UL
600 V (AC)
Max. pitch units @ 45 mm
9
Note
The technical data may vary for UL applications
For mounting on support rails
Yes
for mounting plate assembly
Yes
Number of poles
3-pole
Dimensions
Width: 405 mm | Height: 160 mm | Depth: 45.1 mm
Packs of
1 pc(s).
Weight/pack
1.377 kg
Copper weight (kg per piece)
0.551
Customs tariff number
85469010
EAN
4028177817401
ETIM 9
EC001522
ETIM 8
EC001900
ECLASS 8.0
27400613
Product description
SV Board, 125 A, 690 V (AC). 600 V (DC), 3-pole, WHD: 405x160x45,1 mm
Feature: Shock-hazard-protected busbar board with integral busbars enables safe accommodation and contacting of components through simple plug-in mounting. Business Impact: Reduces wiring risk during installation, speeds commissioning, and minimizes error-prone manual wiring, delivering consistent assembly outcomes while maintaining clear conductor separation. Application: Ideal for control cabinets and compact power-distribution enclosures where quick access and reliable busbar interfaces are essential for uptime. Feature: High electrical ratings—125 A max current, 690 V AC (600 V DC UL)—support mid-range power distribution without multiple submodules. Business Impact: Fewer components and simplified protection schemes reduce total cost of ownership and heat generation. Application: Suitable for machine automation cabinets, panel feeders, and switchgear sections requiring UL 508 compliance and robust performance. Feature: Fire-retardant materials (polyamide, polycarbonate) with copper busbars and UL94 flame protection, color finished in RAL 7035. Business Impact: Improves safety margins, reduces risk of flame propagation, and supports regulatory compliance across markets. Application: Enclosures where predictable material behavior under electrical load and long-term reliability are critical. Feature: Precise dimensions 405x160x45.1 mm, 3-pole layout, max 9 pitch units @ 45 mm, and dedicated mounting provisions for rails and plates. Business Impact: Optimizes space planning, increases modularity, and enables scalable layouts for growing systems. Application: Uses in compact control panels, distribution enclosures, and switchgear where dense wiring and straightforward maintenance are priorities. Feature: Installation versatility with mounting on DIN rails and mounting plates, supply includes integral busbars, and packaging of 1 piece per pack (weight 1.377 kg; copper weight 0.551 kg). Business Impact: Speeds procurement, reduces on-site handling, and provides predictable logistics. Application: Ideal for panel builders needing consistent part numbers and traceable copper content.
Get a Quick Quote for a Rittal 9635010
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9635010?
Enquire Now
FAQs
Yes. The SV Board 9635010 is designed for mounting on support rails (DIN rails) and mounting plates, enabling flexible integration into standard control panels and modular power-distribution enclosures. This compatibility supports fast retrofits and scalable installations, reducing engineering and mounting time while preserving reliable busbar contact integrity.
The board is rated for 125 A maximum current, with a rated operating voltage of up to 690 V AC (600 V DC UL). It is a 3-pole design with IP20 protection and UL 508 compliance. Materials include polyamide, polycarbonate, and copper, with UL94 fire protection, ensuring safe operation in industrial environments.
Ideal for control cabinets, motor drives, and switchgear assemblies requiring compact, plug-in busbar interfaces. Its integral busbars and high current capability support reliable power distribution in machine automation, robot cells, and modular panel buildings, where fast commissioning, easy maintenance, and regulatory compliance are critical.
It complies with UL 508 and UL 94 flame protection, with IP20 protection. This combination is important for safety, regulatory acceptance, and cross-border deployments in Europe and North America, ensuring that the busbar assembly meets electrical, fire-safety, and environmental requirements in industrial environments.
The integrated busbars, quick plug-in mounting, and compatibility with rails and plates reduce installation time and commissioning labor, lower wiring errors, and simplify future upgrades. The copper busbar design provides stable, low-impedance connections, contributing to improved reliability and reduced maintenance costs over the product lifecycle.
