Rittal 9661120 Busbar E-Cu - Ø14 mm holes, direct install
Part Number: 9661120
Quick Summary
Rittal 9661120 Busbar E-Cu is designed for direct installation in enclosures to deliver clean, reliable power distribution. This copper busbar simplifies conductor routing and reduces wiring complexity in compact panel layouts. A common pain point is securing connections in space-constrained cabinets while maintaining electrical integrity; SV 9661.120 addresses this with a robust 10 x 80 mm cross-section and precise Ø14 mm mounting holes. It aligns with industry classifications such as ETIM EC002525 and ECLASS 27400605, ensuring proven data compatibility for design and procurement. By choosing this busbar, users gain predictable performance, smooth enclosure integration, and improved total cost of ownership through reduced assembly time and better thermal management.
Product Information
Extended Description
9661120 Rittal: SV Busbar E-Cu, WH: 80x10 mm, L: 1192mm, with integral holes Ø 14 mm
Article number
SV 9661.120
Product description
Suitable for direct installation in enclosures, busbar supports 9340.000/.010. 9340.004, 9342.014, 3052.000 and 3073.000. PE/PEN combinations in conjunction with PE/PEN combination angle and baying bracket E-Cu.
Material
E-Cu
Ø hole
14 mm
Dimensions
Length: 1,192 mm
To fit
Width: = 1,200 mm
Cross-section
10 mm x 80 mm
Packs of
2 pc(s).
Weight/pack
17.104 kg
Copper weight (kg per piece)
8.45
Customs tariff number
74071000
EAN
4028177494787
ETIM 9
EC002525
ECLASS 8.0
27400605
Product description
SV Busbar E-Cu, WH: 80x10 mm, L: 1192mm, with integral holes Ø 14 mm
Feature cross-section provides higher current capacity with lower contact resistance, delivering a measurable business impact: improved electrical performance in tight panel spaces. Application includes direct installation in enclosures and compatibility with common busbar supports, enabling faster installation and fewer parts. Feature length of 1,192 mm optimizes enclosure width usage and reduces awkward splices, translating to time savings on assembly lines and lower risk of misalignment. Feature Ø14 mm holes simplify mounting with standard hardware, improving repeatability across multiple cabinets and minimizing field modifications. Feature copper weight per piece of 8.45 kg and pack weight of 17.104 kg in packs of two aid precise load planning and logistics, lowering shipping costs per install. Feature compatibility with PE/PEN combinations and E-Cu baying brackets supports versatile grounding schemes, reducing part counts and stocking requirements. This combination of specifications reflects real-world panel-building needs, resulting in more consistent performance, easier maintenance, and better lifecycle costs.
Get a Quick Quote for a Rittal 9661120
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9661120?
Enquire Now
FAQs
SV 9661.120 is designed for direct enclosure installation and works with busbar supports such as 9340.000/.010, 9340.004, and 9342.014, as well as integration with PE/PEN combinations using E-Cu baying brackets.
Key specs include cross-section 10 mm x 80 mm, length 1,192 mm, Ø holes 14 mm, material E-Cu, and copper weight 8.45 kg per piece; packs contain 2 pieces with total pack weight 17.104 kg.
Yes. The product description notes PE/PEN combinations in conjunction with PE/PEN combination angle and baying bracket E-Cu, enabling flexible grounding and conductor layouts without extra parts.
The product is classified under ETIM 9 EC002525 and ECLASS 8.0 27400605. It ships as 2 pieces per pack, with a total pack weight of 17.104 kg.
Benefits include streamlined installation due to standardized Ø14 mm mounting holes, predictable copper weight for load planning, compatibility with common enclosure supports, and reduced assembly time, contributing to lower lifecycle costs.
