Rittal 9661160 SV Busbar E-Cu - 80x10 mm, 14 mm holes
Part Number: 9661160
Quick Summary
SV Busbar E-Cu from Rittal enables direct enclosure mounting for robust, high-current busbar runs. This solution addresses common installation challenges such as precise alignment, weight handling, and ease of integration with PE/PEN configurations in modern control cabinets. It aligns with CE-marked electrical installations and is designed to work with typical IP-rated enclosures, supporting industry-standard classifications for clear traceability. By combining durable copper with a compact footprint, it delivers reliable performance, lowers maintenance needs, and reduces total installed cost. For engineers and procurement teams, these attributes translate into faster assembly, predictable lead times, and safer, compliant switchgear layouts.
Product Information
Extended Description
9661160 Rittal: SV Busbar E-Cu, WH: 80x10 mm, L: 592mm, with integral holes Ø 14 mm
Article number
SV 9661.160
Product description
Suitable for direct installation in enclosures, busbar supports 9340.000/.010. 9340.004, 9342.014, 3052.000 and 3073.000. PE/PEN combinations in conjunction with PE/PEN combination angle and baying bracket E-Cu.
Material
E-Cu
Ø hole
14 mm
Dimensions
Length: 592 mm
To fit
Width: = 600 mm
Cross-section
10 mm x 80 mm
Packs of
2 pc(s).
Weight/pack
8.444 kg
Copper weight (kg per piece)
4.17
Customs tariff number
74071000
EAN
4028177494756
ETIM 9
EC002525
ECLASS 8.0
27400605
Product description
SV Busbar E-Cu, WH: 80x10 mm, L: 592mm, with integral holes Ø 14 mm
Feature: Direct enclosure installation and compatibility with busbar supports 9340.000/.010, 9340.004, 9342.014, 3052.000 and 3073.000. Business Impact: Speeds up panel assembly and reduces misalignment risk, improving on-site reliability. Application: Ideal for HVAC and industrial automation cabinets that require ready-to-mount E-Cu busbars. Feature: Material and cross-section 10 mm x 80 mm E-Cu with integral Ø14 mm holes and 592 mm length. Business Impact: Delivers high current distribution with excellent mechanical strength while maintaining a compact form factor. Application: Suitable for dense control panels where space and conductivity matter. Feature: Pack quantity 2 pcs per pack and weight per pack 8.444 kg. Business Impact: Optimizes logistics, simplifies stock management, and supports easier transport to installation sites. Application: Useful for project-based deployments or multi-panel deployments where consistent spare parts are beneficial. Feature: PE/PEN compatibility with relevant angle and baying brackets. Business Impact: Simplifies copper busbar routing and PE/PEN integration, reducing error-prone wiring. Application: Enables compliant PE/PEN distribution in machinery and process equipment. Feature: Certifications and classifications ETIM EC002525 and ECLASS 27400605. Business Impact: Ensures compatibility with digital catalogs and procurement systems, improving part traceability. Application: Supports data-driven sourcing and standardized maintenance records.
Get a Quick Quote for a Rittal 9661160
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9661160?
Enquire Now
FAQs
Yes. SV Busbar E-Cu 9661.160 is designed for direct installation in enclosures and is compatible with busbar supports such as 9340.000/.010, 9340.004, 9342.014, 3052.000 and 3073.000, with Ø14 mm mounting holes to ensure precise alignment and robust mechanical stability.
Key specs include copper material (E-Cu), cross-section 10 mm x 80 mm, length 592 mm, mounting holes Ø14 mm, and a weight of 4.17 kg per piece (8.444 kg per pack of 2). The product fits enclosure widths up to 600 mm and uses standard PV/PE configurations in copper busbar routing.
Yes. The SV Busbar E-Cu 9661.160 is specified for PE/PEN combinations in conjunction with PE/PEN combination angles and baying brackets, simplifying compliant power distribution within enclosures and improving wiring organization for safety-critical applications.
The product is cataloged under ETIM 9 EC002525 and ECLASS 8.0 27400605, with GTIN 4028177494756 and EAN 4028177494756. These classifications aid with digital procurement, cataloging, and interoperability across engineering and ERP systems.
The busbar’s 80x10 mm cross-section and 14 mm holes enable reliable high-current distribution with minimal assembly time. Pack quantity 2 simplifies stocking, reducing downtime for replacements, while compatibility with standard enclosure supports decreases commissioning risk and long-term maintenance costs.
