Rittal 9666520 SV Busbar module - 1 WU, 2 U
Part Number: 9666520
Manufacturer
Rittal
Part number
9666520
Alt Part Number
SV 9666.520
Quick Summary
Rittal 9666520 SV Busbar module is a configuration accessory that enables bus-mounting fuse bases and NH fuse-switch disconnectors within enclosure systems. This module simplifies integration, reducing installation time and potential wiring errors. Engineers often struggle with space constraints and misalignment when mounting busbars; the SV busbar module delivers precise 1 WU (250 mm) width and 2 U (300 mm) height to fit standard layouts. It adheres to industry classifications such as ETIM EC002525 and ECLASS 27400610, supporting interoperability across procurement and maintenance workflows. By standardizing mounting geometry and material choices, it also streamlines spare-part management and serviceability, delivering measurable efficiencies for panel builders and maintenance teams.
Product Information
Extended Description
9666520 Rittal: SV Busbar module (ISV), 1 WU (250 mm), 2 U (300 mm)
Article number
SV 9666.520
Product description
For assembling bus-mounting fuse bases E18, E27, E33 and D-Switch as well as NH fuse-switch disconnectors, sizes 000 and 00 (3-pole, 60 mm bar centre distance).
Material
Cover: Polystyrene | Holder: Fibreglass-reinforced plastic
Colour
RAL 7035
Supply includes
Assembly parts
Dimensions
Width: 250 mm | Height: 300 mm
Size
Width units (WU) @ 250 mm: 1 | Height units (U) @ 150 mm: 2
To fit Model No.
3418.010
To fit busbars
12 x 5/10 mm
Packs of
1 pc(s).
Weight/pack
0.74 kg
Customs tariff number
85369095
EAN
4028177676404
ETIM 9
EC002525
ECLASS 8.0
27400610
Product description
SV Busbar module (ISV), 1 WU (250 mm), 2 U (300 mm)
Feature: Compact chassis supports 1 WU by 2 U footprint. Business Impact: Reduces enclosure width and simplifies cable routing, enabling denser, more accessible switchgear assemblies. Application: Ideal for Rittal enclosures in automation panels where space is at a premium and serviceability matters. Feature: Durable materials — cover in polystyrene, holder in fibreglass-reinforced plastic. Business Impact: Enhances safety and longevity in harsh environments, minimizing replacement cycles and maintenance costs. Application: Used in industrial control panels requiring flame retardancy and robust mounting. Feature: Compatibility with E18, E27, E33 fuse bases and D-Switch NH disconnectors (3-pole, 60 mm bar center distance). Business Impact: Streamlines procurement and spares, reducing assembly time and potential fit issues. Application: Suitable for standardized protective device configurations in panel builds. Feature: Clear dimensions and busbar fit — 250 mm width, 300 mm height; supports 12 x 5/10 mm busbars. Business Impact: Ensures precise fit within common enclosure footprints, boosting installation predictability. Application: Used for configuring ISV busbar modules in 250x300 mm spaces. Feature: Included assembly parts and a 0.74 kg per-pack weight. Business Impact: Facilitates quick, tool-assisted installation and predictable shipping logistics. Application: Supports rapid field updates and modular upgrades in existing systems.
