Rittal 9666711 SV Mounting angle - 11 U (1650 mm)
Part Number: 9666711
Manufacturer
Rittal
Part number
9666711
Alt Part Number
SV 9666.711
Quick Summary
Rittal 9666711 SV Mounting angle is designed for vertical subdivision of the support frame in VX/TS/SE enclosures, enabling flexible interior layouts. Engineers often need quick reconfigurations as equipment changes, and this ISV mounting angle supports modular partitions without rework. Note that explicit SIL, CE, or IP certifications are not listed for this SKU, but it aligns with industry-standard classifications such as ETIM EC002525 and ECLASS 27400613 to support interoperability. With a zinc-plated sheet steel build and a clear 11 U, 1650 mm profile, it offers robust structure with installation simplicity. This combination reduces changeover time and supports scalable, cost-effective enclosure designs.
Product Information
Extended Description
9666711 Rittal: SV Mounting angle (ISV), 11 U (1650 mm), for TS, SE
Article number
SV 9666.711
Product description
For vertical sub-division of the support frame in the enclosure.
Material
Sheet steel
Surface finish
Zinc-plated
Dimensions
Height: 1,650 mm
Size
Height units (U) @ 150 mm: 11
Packs of
2 pc(s).
Weight/pack
4.06 kg
PCF per pack (cradle-to-gate)
15.5 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177691544
ETIM 9
EC002525
ECLASS 8.0
27400613
Product description
SV Mounting angle (ISV), 11 U (1650 mm), for TS, SE
Feature: SV ISV mounting angle provides vertical subdivision for TS, SE, VX enclosure frames with a fixed 11 U height (1,650 mm). Business Impact: enables predictable rack partitioning and faster reconfiguration when equipment changes occur. Application: ideal for modular internal layouts in VX/TS/SE families, reducing retrofit time and preserving rail alignment. Feature: Made from sheet steel with a zinc-plated finish. Business Impact: delivers rugged durability and corrosion resistance for long service life in factory environments. Application: indoor electrical infrastructure within data centers and control panels. Feature: Packs of 2 pcs; Weight per pack 4.06 kg; PCF per pack 15.5 kg CO2 eq (Cat B). Business Impact: efficient handling and credible sustainability metrics, aiding procurement and lifecycle assessments. Application: batch ordering for scalable projects and responsible design. Feature: EAN 4028177691544; Customs tariff number 73269098; ETIM 9 EC002525; ECLASS 8.0 27400613. Business Impact: enhances sourcing accuracy, interoperability, and regulatory compliance in supply chains. Application: essential for cataloging, ERP integration, and cross-vendor compatibility. Feature: Product supports TS and SE enclosures and is compatible with VX families for vertical partitioning. Business Impact: improves install velocity, reduces site downtime, and increases rack density. Application: suitable for modular industrial control cabinets and electrical infrastructure projects.
Get a Quick Quote for a Rittal 9666711
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9666711?
Enquire Now
FAQs
The SV ISV mounting angle is designed to mount within TS and SE enclosure frames, enabling vertical subdivision of the support structure. Install in pairs (two per pack) to maintain balanced alignment with existing rails, ensuring proper clearance for cables and equipment. Verify support frame compatibility with VX/TS/SE families before mounting, and follow standard enclosure assembly practices for best results.
Yes. The mounting angle is specified for TS and SE and is intended for vertical subdivision of the support frame in VX/TS/SE enclosure families, providing flexible internal partitioning without modifying the main frame. This compatibility streamlines retrofits and future reconfigurations across multiple enclosure lines.
Key specs include a height of 1,650 mm (11 U), material sheet steel with a zinc-plated finish, and packaging of 2 units per pack with a weight of 4.06 kg per pack. The article number is SV 9666.711, and the EAN is 4028177691544, aiding precise ordering and inventory control.
The product provides cradle-to-gate PCF data of 15.5 kg CO2 eq per pack (Category B), reflecting environmental considerations tied to weight. This supports lifecycle assessments and sustainability reporting. For procurement, note that exact certifications like SIL or CE are not listed for this SKU.
Official installation instructions are available as PDFs via the product downloads. Look for the main variant page 9666711 and the document set '9666711_Instructions_DE_EN_FR' to access DE, EN, and FR guidance. These resources help ensure correct mounting, safety, and best-practice wiring and cable management.
