Rittal SV 9666.801 ISV Kit for AX/AE - WHD 380x600x210
Part Number: 9666801
Manufacturer
Rittal
Part number
9666801
Alt Part Number
SV 9666.801
Quick Summary
The SV Installation kit SV 9666.801 is a complete mounting solution that enables secure ISV module installation inside AX/AE enclosures. Engineers often struggle with misalignment and limited space when retrofitting ISV modules, leading to longer commissioning times. In regulated environments, CE marking and IP-rated protection are critical considerations, along with SIL-driven safety planning. This kit delivers a precise fit, robust construction, and straightforward installation, supporting standardized, efficient panel builds while reducing risk and downtime. By aligning with established enclosure practices and leveraging common procurement identifiers, it also helps streamline purchasing and project scheduling for industrial automation projects.
Product Information
Extended Description
9666801 Rittal: SV Installation kit (ISV), 1 WU (250 mm), 3 U (450 mm), for AE (WHD: 380x600x210 mm)
Article number
SV 9666.801
Product description
For mounting ISV installation modules in enclosures.
Material
Assembly kit: Sheet steel, zinc-plated | Support rail: Sheet steel, zinc-plated | Contact hazard protection: Sheet steel, spray-finished
Supply includes
Assembly kit | Support rails | Contact hazard protection | Assembly parts
Size
Width units (WU) @ 250 mm:Â 1 | Height units (U) @ 150 mm:Â 3
To fit Model No.
1008.000
To fit
Enclosure type:Â AX | Width:Â 380 mm | Height:Â 600 mm | Depth:Â 210 mm
Packs of
1 pc(s).
Weight/pack
4.44 kg
Customs tariff number
83024900
EAN
4028177803794
ETIM 9
EC002525
ECLASS 8.0
27400613
Product description
SV Installation kit (ISV), 1 WU (250 mm), 3 U (450 mm), for AE (WHD: 380x600x210 mm)
Feature: Precise mounting footprint with 1 WU (250 mm) and 3 U (450 mm) dimensions ensures ISV modules mount without interference. Business Impact: Reduces alignment errors and rework, accelerating project timelines and lowering commissioning costs. Application: Ideal for AX/AE enclosure workflows where ISV modules must be securely positioned inside a 380x600x210 mm space. Feature: Durable sheet steel construction with zinc-plated rails and spray-finished contact hazard protection. Business Impact: Improves longevity in harsh industrial environments and enhances operator safety. Application: Suitable for long-life cabinet installations in manufacturing or process automation environments. Feature: Comprehensive supply includes assembly kit, support rails, protection components, and assembly parts. Business Impact: Enables faster on-site installation with fewer separate parts, reducing BOM handling and field sourcing. Application: Streamlines procurement and assembly for standard enclosure projects. Feature: Defined fitment for AX enclosures and clear compatibility with AE variants, including Model No. 1008.000. Business Impact: Minimizes misfit risk and compatibility issues across inventory and projects. Application: Supports standardized rack design across multiple lineups and upgrade paths. Feature: Lightweight packaging at 4.44 kg per pack and single-pack delivery. Business Impact: Eases handling and reduces labor time during installation and maintenance. Application: Beneficial for small teams performing cabinet upgrades in tight production areas. Feature: Alignment with ETIM 9 EC002525 and ECLASS 8.0 27400613 classifications. Business Impact: Improves procurement accuracy and supplier communication. Application: Helps integrate the SV kit into ERP and MRO workflows for better lifecycle management.
