Rittal 9671204 SV 9671.204 Perforated Strip - 25 mm pitch
Part Number: 9671204
Quick Summary
SV Perforated mounting strip is a retrofitting solution that enables external mounting on partial cabinet doors, using a 25 mm hole pitch for rear-door accessory mounting such as cable ducts and hose holders. This design addresses the common challenge of upgrading enclosures without compromising door integrity or interior space. It aligns with ETIM 9 EC002525 and ECLASS 8.0 27400501 standards, supporting consistent data and procurement workflows, while CE compliance is maintained where applicable. For integrators and procurement teams, this part offers a predictable fit and fast installation, reducing downtime and ensuring a tidy, standards-driven retrofit. The product also complements door-mounting strategies and cabinet accessories, helping you optimize space and wiring management across WH widths from 400 to 800 mm.
Product Information
Extended Description
9671204 Rittal: SV Perforated mounting strip, L: 298 mm, for partial door WH: 400x150-800 mm
Article number
SV 9671.204
Product description
For retrospective external mounting on partial doors. The perforated mounting strips have a 25 mm pitch pattern of holes and may be used for individual mountings on the rear of doors, e.g. cable ducts, hose holders etc. Hole diameter of perforated mounting strip: 4.5 mm
Material
Sheet steel, 1 mm
Surface finish
Zinc-plated
Supply includes
Assembly parts
Length
298 mm
Dimensions
Length: 298 mm
To fit
Width: = 400 mm
OUT_SUITABLE_FOR_PARTIAL_DOOR_HEIGHTS
150 ‐ 800 mm
Packs of
10 pc(s).
Weight/pack
0.89 kg
Customs tariff number
39269097
EAN
4028177619616
ETIM 9
EC002525
ECLASS 8.0
27400501
Product description
SV Perforated mounting strip, L: 298 mm, for partial door WH: 400x150-800 mm
Feature: 25 mm hole pitch with 4.5 mm holes on a 298 mm strip. Business Impact: Enables flexible retrofits without door modification, reducing installation time and material waste. Application: Use for attaching cable ducts and hose holders to the rear of partial doors in Rittal enclosures. Feature: Sheet steel 1 mm with zinc-plated surface. Business Impact: Provides corrosion resistance and durability in industrial environments, lowering maintenance needs and lifecycle costs. Application: Suitable for outdoor or harsh indoor settings where dust, moisture, and handling occur. Feature: Length 298 mm; fits WH sizes 400x150–800 mm. Business Impact: Standardized mounting footprint across common door sizes, improving compatibility and stocking efficiency. Application: Ideal for modular configurations and scalable panel layouts. Feature: Pack of 10 with weight 0.89 kg per pack and assembly parts included. Business Impact: Improves logistics, reduces per-unit cost, and simplifies on-site assembly with all required hardware included. Application: Fast replacement and predictable inventory planning. Feature: Article number SV 9671.204, EAN 4028177619616, customs tariff 39269097. Business Impact: Streamlines procurement, customs handling, and cross-border shipping. Application: Useful for global supply chains and compliance documentation. Industry context: The strip supports retrofitting in enclosure systems where rear-door mounting is preferred for cable management and accessory integration, aligning with ETIM/ECLASS data standards to support digital catalogs and BOM generation. This leads to measurable improvements in wiring organization, serviceability, and overall enclosure reliability.
Get a Quick Quote for a Rittal 9671204
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9671204?
Enquire Now
FAQs
The installer aligns the 298 mm strip to the door, uses the 25 mm hole pitch to position fasteners, and mounts cable ducts or hose holders on the rear of the door. The kit includes assembly parts for quick, non-destructive mounting on WH widths from 400x150 to 800 mm.
Key specs include length 298 mm, hole pitch 25 mm, hole diameter 4.5 mm, material sheet steel 1 mm, zinc-plated finish, and pack size of 10 with a total weight of 0.89 kg per pack. It fits partial doors within 400x150–800 mm and accommodates rear-mounted accessories.
Yes. The perforated strip is designed for retrospective external mounting on partial doors and supports rear-door installations such as cable ducts and hose holders, enhancing wiring management without interior modifications.
The product data references ETIM 9 EC002525 and ECLASS 8.0 27400501 for classification and interoperability. CE compliance is noted where applicable, and the item carries the EAN 4028177619616 for traceability and procurement.
By enabling quick, non-destructive retrofits with assembly parts included and a durable zinc-plated finish, the strip reduces installation time, minimizes door modifications, and lowers long-term maintenance costs through reliable, organized rear mounting of accessories.
