Rittal 9671208 SV Perforated mounting strip - 25 mm pitch
Part Number: 9671208
Quick Summary
Rittal 9671208 is a perforated mounting strip designed for retrospective external mounting on partial cabinet doors. This solution addresses the challenge of adding accessories like cable ducts and hose holders without compromising door integrity or alignment. It aligns with industry-standard classifications such as ETIM 9 EC002525 and ECLASS 8.0 27400501, supporting precise procurement and data consistency, while the zinc-plated finish provides corrosion resistance for longer service life. By enabling rear-door mounting with a consistent 25 mm hole pitch, this strip reduces bespoke hardware needs and accelerates installation, delivering measurable gains in efficiency and project uptime for enclosure assemblies and industrial cabinets.
Product Information
Extended Description
9671208 Rittal: SV Perforated mounting strip, L: 698 mm, for partial door WH: 800x150-800 mm
Article number
SV 9671.208
Product description
For retrospective external mounting on partial doors. The perforated mounting strips have a 25 mm pitch pattern of holes and may be used for individual mountings on the rear of doors, e.g. cable ducts, hose holders etc. Hole diameter of perforated mounting strip: 4.5 mm
Material
Sheet steel, 1 mm
Surface finish
Zinc-plated
Supply includes
Assembly parts
Length
698 mm
Dimensions
Length: 698 mm
To fit
Width: = 800 mm
OUT_SUITABLE_FOR_PARTIAL_DOOR_HEIGHTS
150 ‐ 800 mm
Packs of
10 pc(s).
Weight/pack
2.02 kg
Customs tariff number
39269097
EAN
4028177619630
ETIM 9
EC002525
ECLASS 8.0
27400501
Product description
SV Perforated mounting strip, L: 698 mm, for partial door WH: 800x150-800 mm
Feature → Business Impact → Application: The SV 9671.208 uses a 25 mm hole pitch with 4.5 mm holes, enabling flexible attachment opportunities and reducing the need for custom brackets. This translates to faster retrofits on existing cabinets and lower installation labor costs in panel-building projects. Application: suitable for mounting cable ducts, hose holders, and other rear-door accessories on partial doors up to 800 mm wide and 150–800 mm high, making it ideal for retrofit work in control panels and enclosure systems. Feature → Business Impact → Application: The strip is sheet steel, 1 mm thick, and zinc-plated, delivering durable corrosion resistance with a cost-effective profile. This supports longer service life in challenging industrial environments while keeping maintenance overhead low. Application: contributes to compliant, long-lasting mounting solutions for industrial automation, especially where frequent accessory changes are expected.
Get a Quick Quote for a Rittal 9671208
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9671208?
Enquire Now
FAQs
To install, confirm door width up to 800 mm and height range 150–800 mm. Align the 25 mm pitch holes on the mounting strip with the door’s rear surface, secure using the included assembly parts, and distribute loads evenly to avoid deformation. Each pack contains 10 strips for bulk projects.
The strip measures 698 mm in length with a 25 mm hole pitch and 4.5 mm hole diameter. It is made from 1 mm thick sheet steel and zinc-plated for corrosion resistance, designed for external retrofits on partial doors (800x150–800 mm).
The zinc-plated finish provides corrosion protection suitable for many industrial environments. For severe outdoor exposure or wash-down areas, verify additional protective measures and enclosure sealing, as the data does not specify an IP rating for this strip.
The part aligns with ETIM 9 EC002525 and ECLASS 8.0 27400501 for procurement and cataloging. EAN is 4028177619630, and the product description confirms its use for partial-door retrofits and rear-door mounting inside cabinets.
Each pack includes assembly parts for quick installation, and packaging supports 10 strips per pack, reducing procurement complexity. The standardized 25 mm pitch enables repeatable configurations across multiple enclosures, lowering labor time and minimizing bespoke hardware costs during retrofits.
