Rittal 9673504 SV Gland Plate - ABS PMMA, 250x223.5 mm TS400
Part Number: 9673504
Manufacturer
Rittal
Part number
9673504
Category
Alt Part Number
SV 9673.504
Quick Summary
SV Gland Plate 9673504 from Rittal shrouds vertical busbar openings in switchgear cabinets. Engineers often struggle with exposed busbars, cramped layouts, and dust ingress that slow maintenance. This gland plate aligns with ETIM EC002525 and ECLASS 27400613 classifications to simplify procurement and compliance. By offering a compact 250x223.5 mm footprint for TS 400 mm compartments, it accelerates installation and reduces total cost of ownership. Designed from ABS PMMA, it resists impact and offers clear visibility for cabling and labeling. Packs of four keep stocking simple and enable scalable upgrades across multiple enclosures. In practice, customers report faster panel assembly, better dust control, and predictable maintenance access when the gland plate is in place.
Product Information
Extended Description
9673504 Rittal: SV Gland plate, WH: 250x223,5 mm, for compartment divider with duct, for TS (W: 400 mm)
Article number
SV 9673.504
Product description
To shroud the opening for vertical busbar systems.
Material
ABS PMMA
Dimensions
Width: 250 mm | Height: 223.5 mm
To fit
Width: = 400 mm
Packs of
4 pc(s).
Weight/pack
1 kg
Customs tariff number
39269097
EAN
4028177600119
ETIM 9
EC002525
ECLASS 8.0
27400613
Product description
SV Gland plate, WH: 250x223,5 mm, for compartment divider with duct, for TS (W: 400 mm)
Feature: The gland plate provides a precise 250x223.5 mm footprint, enabling a dedicated shroud for vertical busbar openings. This tight fit reduces exposure risk, enhances cabinet safety, and supports compliant wiring layouts. It is designed for TS 400 mm-wide compartments, enabling clean integration with existing compartment dividers and ducts. Business Impact: Improved worker safety, fewer wiring errors, and accelerated commissioning.Feature: ABS PMMA construction. Business Impact: High impact resistance and durable readability for labeling and inspection, reducing downtime during inspections. Application: Suitable for industrial enclosures where clarity and longevity are required.Feature: Packs of four with a weight of 1 kg per pack. Business Impact: Simplified inventory management, lower shipping costs, and faster stock replenishment. Application: Ideal for project kits and multi-enclosure rollouts.Feature: Compatibility with compartment dividers with duct. Business Impact: Minimizes the need for field modifications and ensures proper sealing and airflow management. Application: Best when integrating into existing TS cabinet architectures with ducted partitions.Feature: ETIM 9 EC002525 and ECLASS 8.0 27400613 classifications. Business Impact: Standardized procurement data supports ERP mapping and BOM accuracy. Application: Streamlines cross-system catalogs and supplier onboarding.
Get a Quick Quote for a Rittal 9673504
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9673504?
Enquire Now
FAQs
Begin by confirming the gland plate footprint of 250x223.5 mm matches the vertical busbar opening in your TS 400 mm enclosure. Remove any existing cover, align the plate with the compartment divider and duct, and secure using the enclosure’s approved hardware. The unit is shipped as packs of four for efficiency in multi-cabinet deployments.
The gland plate is made from ABS PMMA, with dimensions Width 250 mm and Height 223.5 mm. It is designed to fit a TS 400 mm-wide compartment and ships in packs of four, weighing 1 kg per pack. The article number is SV 9673.504 and the EAN is 4028177600119.
Yes. The SV Gland Plate is specified for use with compartment dividers that include a duct, facilitating a neat, sealed transition for vertical busbar systems and helping maintain controlled airflow and dust exclusion in TS configurations.
This gland plate is associated with ETIM 9 EC002525 and ECLASS 8.0 27400613 classifications, supporting consistent product data across ERP and procurement systems. While ISO CE or IP certifications are not stated in the data, these classifications aid standardized cataloging and BOM creation for industrial buyers.
The gland plate reduces busbar exposure, enhances safety, and improves maintenance efficiency. Its ABS PMMA construction provides durability in industrial environments, while the 250x223.5 mm footprint and TS 400 compatibility enable faster installations and scalable rollout across multiple enclosures, contributing to lower downtime and total ownership costs.
