Rittal 9674782 SV Frame - DIN Rail 2x36 Pitch
Part Number: 9674782
Manufacturer
Rittal
Part number
9674782
Category
Alt Part Number
SV 9674.782
Quick Summary
SV 9674.782 DIN rail frame houses DIN rail devices like MCBs in compact enclosures. This frame helps prevent cross-wiring and internal clutter by providing stable rails and clear compartmentalisation. It aligns with ETIM 9 EC001900 and ECLASS 8.0 27400613 standards, and typical European panels also reference CE conformity—verify exact certifications for your project. For added value, the frame integrates with compartment dividers and side panel modules to enable scalable, modular installations, delivering faster setup, easier maintenance, and consistent panel quality across production lines.
Product Information
Extended Description
9674782 Rittal: SV Support frame, for DIN rail-mounted devices, 2 x 36 pitch units, WH: 700x295 mm
Article number
SV 9674.782
Product description
Support frame set for accepting DIN rail-mounted devices (e.g. MCBs). The support rails are fastened with two mounting brackets to the side panel modules for internal compartmentalisation. The cover is fastened to the support frame with knurled screws. In combination with compartment dividers, partial mounting plates and side panel modules, internal compartmentalisation in accordance with Form 2, 3 or 4 is possible.
Material
Support frame: Sheet steel, zinc-plated, passivated, 1.5 mm | Cover: Sheet steel, spray finished, 1.5 mm
Supply includes
Support rails | 2 mounting brackets | 1 cover with cut-out | Assembly parts
For compartment height
300 mm
To fit
Width:Â = 800 mm
No. of pitch units 17.5 mm
2 x 36
Packs of
1 pc(s).
Weight/pack
4.6 kg
Customs tariff number
73269098
EAN
4028177543843
ETIM 9
EC001900
ECLASS 8.0
27400613
Product description
SV Support frame, for DIN rail-mounted devices, 2 x 36 pitch units, WH: 700x295 mm
Robust material and corrosion-resistant design → Extends service life and minimizes maintenance in harsh industrial environments; ideal for control panels and distributed power assemblies. 2x36 pitch units with 700x295 mm footprint → Maximizes device density while preserving accessibility for MCBs and DIN rail accessories, enabling compact but capable distributions. Supplied with rails, two mounting brackets, one cover with a cut-out, and assembly parts → Reduces procurement steps and on-site assembly time, cutting project timelines and labor costs. Internal compartmentalisation support via dividers and optional mounting plates → Allows Form 2, 3 or 4 layouts, improving cable management and fault isolation for safer operation and faster troubleshooting. Knurled-screw cover and side-panel mounting → Simplifies field service and quick access during inspections, minimizing downtime. ETIM 9 EC001900 and ECLASS 8.0 27400613 compatibility → Streamlines cross-vendor cataloging and procurement integration, improving spend visibility and compliance across multiple sites.
