Rittal 9683468 SV Compartment divider - With louvres
Part Number: 9683468
Manufacturer
Rittal
Part number
9683468
Category
Alt Part Number
SV 9683.468
Quick Summary
Rittal SV Compartment divider (9683.468) enables horizontal separation of compartments in VX enclosures. This design helps reduce clutter and simplifies cable routing, addressing common installation challenges faced by panel builders and integrators. It aligns with ETIM 7.0 EC002525 and ECLASS 8.0 27400613 classifications, with a PCF cradle-to-gate footprint in Category B, supporting sustainability goals. For buyers, the divider delivers reliable Form separation in Form 1 to Form 4 configurations while offering straightforward compatibility with existing side panels and assembly parts. This combination of robust construction and standardized data accelerates procurement and reduces lifecycle costs for industrial automation projects.
Product Information
Extended Description
9683468 Rittal: SV Compartment divider, WD: 511x780 mm, for VX (WD: 600x800 mm)
Article number
SV 9683.468
Design
With louvres
Product description
For the horizontal separation of compartments. In combination with the side panels, this creates Form separation to Form 1 to 4. For attachment to the compartment side panel or the enclosure section. The integral cut-outs with pre-punched knock-out option are used for the vertical routing of control lines or cable ducts and for the routing of distribution busbars or connection kits.
Material
Sheet steel, 1.5 mm
Surface finish
Zinc-plated
Supply includes
Assembly parts
Assembly instruction
For assembling compartments as internal Form separation, compartment side panels are required
Dimensions
Width: 511 mm | Depth: 780 mm
To fit
Width: = 600 mm | Depth: = 800 mm
Packs of
2 pc(s).
Weight/pack
6.6 kg
PCF per pack (cradle-to-gate)
25.1 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177936379
ETIM 7.0
EC002525
ECLASS 8.0
27400613
Product description
SV Compartment divider, WD: 511x780 mm, for VX (WD: 600x800 mm)
Feature: With louvres design enables controlled airflow and clear separation between compartments. Business Impact: Improves thermal management and reduces cross-contamination risks, leading to safer, more reliable control panels. Application: Suitable for VX enclosures where compartment zoning and ventilation are critical. Feature: Dimensions 511 mm by 780 mm to fit VX 600x800 mm. Business Impact: Maximizes space utilization and minimizes need for adapters, cutting install time. Application: Ideal for standardized VX enclosures across multiple SKUs. Feature: Material and finish 1.5 mm zinc-plated sheet steel. Business Impact: Delivers durability and corrosion resistance in harsh industrial environments, lowering maintenance costs. Application: Suitable for factory floors with exposure to dust and moisture. Feature: Integral cut-outs and pre-punched knock-outs. Business Impact: Eases vertical routing of control lines and cable ducts, speeding assembly and reducing errors. Application: Supports busbars, connection kits, and clean routing. Feature: Assembly parts included. Business Impact: Streamlines on-site assembly, reducing labor hours and total cost of ownership. Application: Quick integration with compartment side panels for internal Form separation. Feature: Weight per pack 6.6 kg; Packs of 2. Business Impact: Simplifies handling and reduces installation fatigue, improving project timelines. Application: Preferred for modular upgrades and scalable enclosure configurations. Feature: PCF 25.1 kg CO2 eq per pack (Cat B). Business Impact: Demonstrates a lower embodied carbon footprint, supporting sustainability targets. Application: Aligns with green manufacturing programs and supplier ESG requirements.
Get a Quick Quote for a Rittal 9683468
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9683468?
Enquire Now
FAQs
Yes. The SV 9683.468 is designed for VX enclosures with a 600x800 mm footprint. It attaches to the enclosure side panel or the enclosure section, and it ships with assembly parts to facilitate straightforward integration alongside existing side panels and partitioning components.
Key specs include a width of 511 mm and depth of 780 mm, designed to fit VX enclosures of 600x800 mm. It is made from 1.5 mm zinc-plated sheet steel, features louvres, and weighs 6.6 kg per pack (packs of 2). It also supports vertical routing via pre-punched knock-outs and cut-outs for busbars and cables.
Yes. When used with the appropriate compartment side panels, it creates Form separation suitable for Form 1 through Form 4 configurations. The design includes integral cut-outs and knock-outs to facilitate clean cable routing and modular partitioning in multi-form layouts.
The product aligns with ETIM 7.0 EC002525 and ECLASS 8.0 27400613, and its PCF category is B (cradle-to-gate). It also carries the EAN 4028177936379 for traceability and ordering within ERP systems.
The divider delivers tangible benefits: improved cable organization, faster installation through included assembly parts, and reduced service time due to predictable Form separation. With a sustainable PCF footprint (Cat B) and durable zinc-plated steel, it lowers lifecycle costs and supports ESG goals in automation projects.
