Rittal SV 9684.920 Contact Hazard Protection Cover - IP 2X
Part Number: 9684920
Manufacturer
Rittal
Part number
9684920
Category
Alt Part Number
SV 9684.920
Quick Summary
Rittal SV 9684.920 contact hazard protection cover protects NH fuse-switch disconnectors in VX enclosures from finger contact. Maintenance teams frequently face safety gaps when rear sections remain exposed during testing. It delivers IP 2X finger protection and fits VX enclosure widths up to 1,200 mm. The solution aligns with standard procurement data and cataloging through ETIM 9 EC001638 and ECLASS 8.0 27142116, helping buyers source consistently. Overall, it reduces risk, shortens installation time, and supports compliance in panel layouts while enabling reliable, safer operations in power distribution applications.
Product Information
Extended Description
9684920 Rittal: SV Contact hazard protection cover, plate Form 2b (fuse-switch disconnector, section), for VX (W: 1200 mm)
Article number
SV 9684.920
Product description
To cover outgoing sections with NH slimline fuse-switch disconnectors and busbar system in the rear enclosure section so that they are safe from finger contact (IP 2X).
Material
Sheet steel, 1.5 mm
Surface finish
Zinc-plated
Supply includes
4 side panels (left/right side) | 2 side panels (top/bottom) | Assembly parts
Usable width for Flat-PLS
1,000 mm
Note
The specified installation width when using the contact hazard protection cover only applies when using busbar support 9686.060/9686.070
To fit
Enclosure type: TS | Width: = 1,200 mm
Packs of
1 pc(s).
Weight/pack
8.28 kg
PCF per pack (cradle-to-gate)
31.5 kg CO2 eq (Cat B)
Note on PCF category
Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared
Customs tariff number
73269098
EAN
4028177936836
ETIM 9
EC001638
ECLASS 8.0
27142116
Product description
SV Contact hazard protection cover, plate Form 2b (fuse-switch disconnector, section), for VX (W: 1200 mm)
Feature — Durable sheet steel body: The 1.5 mm zinc-plated sheet steel provides rigid protection against knocks and corrosion. Business impact — Longer service life in harsh electrical environments reduces replacement and maintenance costs. Application — Ideal for VX 1200 mm enclosures housing NH fuse-switch disconnectors in distribution panels. Feature — Complete pack contents: 4 side panels (left/right) and 2 top/bottom panels plus mounting hardware. Business impact — Simplified install and rework with a ready-to-assemble kit that minimizes cabinet downtime. Application — Fits rear enclosures with busbar systems in Form 2b arrangements. Feature — Usable width and fitment: Usable width for Flat-PLS is 1,000 mm; installation width requires 1,200 mm enclosure with busbar support 9686.060/9686.070. Business impact — Ensures predictable installation dimensions and avoids overfitting or gaps. Application — Particularly suitable for TS type enclosures with VX 1200 mm width. Feature — Data compatibility and classification: Product data includes ETIM EC001638 and ECLASS 27142116; customs tariff 73269098; EAN 4028177936836. Business impact — Improves procurement accuracy and enables automated catalog workflows. Application — Seamless transfer into ERP and purchasing systems for standardized sourcing. Feature — Sustainability footprint: PCF per pack 31.5 kg CO2 eq (Cat B); weight per pack 8.28 kg. Business impact — Provides cradle-to-gate environmental insight for life-cycle assessments and supplier scoring. Application — Useful for green procurement programs and carbon reporting in electrical components. Feature — Safety certification alignment: IP 2X finger protection rating integrated via protective cover; reduces exposure during maintenance. Business impact — Lowers risk, enables safer maintenance windows, and supports basic electrical safety norms. Application — Suitable for power distribution panels with NH fuse-switch disconnectors.
Get a Quick Quote for a Rittal 9684920
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9684920?
Enquire Now
FAQs
Yes. The SV 9684.920 is designed for VX enclosures with a 1,200 mm width and works with rear busbar systems when used with the specified busbar supports 9686.060/9686.070. The included parts kit (4 side panels, 2 top/bottom panels, and mounting hardware) simplifies installation.
The cover is made from 1.5 mm zinc-plated sheet steel, providing durable mechanical protection and corrosion resistance. It delivers IP 2X finger protection to reduce contact risk when servicing fuse-switch disconnectors in VX enclosures.
It is ideal for TS-type VX enclosures featuring rear busbar systems, where access safety and clean separation of live sections are critical. The 1,000 mm usable width supports standard Flat-PLS configurations in 1,200 mm-wide cabinets.
The product data aligns with ETIM EC001638 and ECLASS 27142116, aiding standardized cataloging. It also references the IP 2X safety rating, reinforcing basic electrical safety in panel assemblies.
The 8.28 kg pack weight and 31.5 kg CO2 eq PCF (Cat B) provide lifecycle insight for sustainability reporting. The durable construction reduces maintenance frequency, minimizes downtime, and supports safer, faster maintenance routines.
