Rittal SV 9686.070 Busbar Holder - UL 94-V0 Certified
Part Number: 9686070
Manufacturer
Rittal
Part number
9686070
Category
Alt Part Number
SV 9686.070
Quick Summary
Rittal SV 9686.070 busbar holder secures 50 x 10 mm busbars in the rear of electrical enclosures for reliable power distribution. Engineers often contend with cramped spaces, unreliable mounting, and insufficient fire protection, which complicate panel builds and maintenance. This solution delivers precise, rigid support in duroplastic with UL 94-V0 fire protection, helping meet stringent safety requirements. The product is classified under ETIM EC001166 and ECLASS 27400607, ensuring consistent cataloging and easier procurement across suppliers. By simplifying installation, offering consistent center-to-center spacing at 185 mm, and enabling up to four busbars per phase, it reduces assembly time, improves electrical safety, and scales with growing panel complexity.
Product Information
Extended Description
9686070 Rittal: SV busbar holder, 3-pole, 185 mm, for E-Cu 50 x 10 mm, duroplastic, fire protection in accordance with UL 94-V0
Article number
SV 9686.070
Product description
|
Material
Duroplastic | Fire protection corresponding to ULÂ 94-V0
Colour
Similar to RALÂ 9005
Supply includes
Assembly parts
To fit busbars
50 x 10 mm
Centre-to-centre spacing of busbars
185 mm
Assembly instruction
For the installation of max. 4 busbars (sub-conductors) per phase
Packs of
2 pc(s).
Weight/pack
3.14 kg
Customs tariff number
85469010
EAN
4028177935686
ETIM 9
EC001166
ECLASS 8.0
27400607
Product description
SV busbar holder, 3-pole, 185 mm, for E-Cu 50 x 10 mm, duroplastic, fire protection in accordance with UL 94-V0
Feature: 3-pole design with 185 mm center-to-center spacing and compatibility with E-Cu 50 x 10 mm busbars. Business Impact: Enables neat, repeatable rear-busbar layouts, reduces alignment errors, and shortens commissioning time. Application: Suitable for Rittal enclosure rear sections and scalable to larger panels; installation supports up to four sub-conductors per phase. Feature: Duroplastic body with UL 94-V0 fire protection. Business Impact: Improves safety in confined cabinets and resists high-temperature conditions, lowering risk during fault events. Application: Critical for electrical cabinets in control rooms and industrial environments. Feature: Pack of 2 with weight 3.14 kg per pack. Business Impact: Streamlines stocking, reduces inventory variance, and lowers shipping costs. Application: Ideal for multi-panel deployments and standard maintenance cycles. Feature: Supply includes assembly parts. Business Impact: Speeds up on-site installation and ensures consistent mounting quality. Application: Ideal for field service teams seeking plug-and-play reliability. Feature: To fit busbars 50 x 10 mm; max four busbars per phase. Business Impact: Supports modular expansion without replacing mounting hardware. Application: Enables phased upgrades in evolving power distribution architectures. Feature: Clear compatibility references with ETIM EC001166 and ECLASS 27400607. Business Impact: Simplifies ERP and catalog alignment, improves procurement accuracy. Application: Reduces mis-picks and ensures compliant part selection for panel builders.
