Rittal 9686420 SV arcing fault kit - Class B
Part Number: 9686420
Manufacturer
Rittal
Part number
9686420
Category
Alt Part Number
SV 9686.420
Quick Summary
SV arcing fault kit provides Class B arc flash protection for VX roof-area enclosures. This solution helps engineers close safety gaps during retrofits and new builds. It supports IEC/TR 61 641 compliance for human safety and equipment protection and is designed for a single VX enclosure panel. By integrating a ready-to-install kit with busbar system assembly in the roof section, it reduces install time and risk. The package aligns with industrial safety standards and delivers tangible business value through improved uptime and predictable maintenance costs.
Product Information
Extended Description
9686420 Rittal: SV arcing fault kit, class B, for VX roof area
Article number
SV 9686.420
Design
For busbar system assembly in the roof section
Product description
To achieve arc flash class B (human safety and protection of equipment) to IEC/TR 61 641. Suitable for one enclosure panel.
Material
Steel | Plastic | Silicone
Supply includes
2 metal covers | 2 roof mounting brackets for sacrificial anodes | Certificate | Assembly parts | 2 metal partitions | 6 sacrificial anodes | 8 seals | 8 plastic covers
Packs of
1 pc(s).
Customs tariff number
83024900
EAN
4028177962835
ETIM 9
EC002498
ECLASS 8.0
27142423
Product description
SV arcing fault kit, class B, for VX roof area
Comprehensive, ready-to-install supply reduces procurement delays and field shortfalls, enabling fast, compliant installations on VX roof-area busbar systems. The kit's inclusion of two metal covers, two roof mounting brackets for sacrificial anodes, two metal partitions, six sacrificial anodes, eight seals, eight plastic covers, assembly parts, and a certificate translates to lower total project cost and fewer site calls. Material composition (steel, plastic, silicone) delivers durability in demanding environments, minimizing replacement cycles and downtime. Designed for one enclosure panel, the system simplifies retrofit planning and ensures consistent arc fault protection where it matters most. Safety and compliance are enhanced through Class B arc flash performance and a documented certificate, supporting regulators and customer audits. Installation advantages include dedicated brackets and parts that streamline mounting on the VX roof area, reducing risk and speeding field work. Overall, this solution aligns with industry best practices for dependable protection, predictable maintenance, and long-term cost avoidance.
Get a Quick Quote for a Rittal 9686420
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9686420?
Enquire Now
FAQs
Installation is straightforward for a VX roof-area enclosure and targets one enclosure panel. The kit includes two metal covers, two roof mounting brackets for sacrificial anodes, two metal partitions, six sacrificial anodes, eight seals, eight plastic covers, assembly parts, and a certificate. Use the brackets to mount the kit on the busbar system in the roof section, following the included instructions.
Arc flash class B denotes a defined level of protection for human safety and equipment during arcing events. Implementing a Class B solution like this kit reduces the energy reaching personnel and sensitive components in the VX roof area, helping to meet safety targets, minimize incident consequences, and support regulatory compliance during routine maintenance and upgrades.
Yes. The kit is designed for busbar system assembly in the VX roof section and is suitable for use with typical VX enclosure configurations. Its mounting brackets and assembly parts are intended to integrate with standard VX busbar layouts, simplifying retrofit projects and ensuring consistent protection without major enclosure redesigns.
Key benefits include enhanced operator safety, reduced arc fault risk to critical equipment, and faster installation with an all-in-one supply. By lowering field errors, minimizing downtime, and streamlining procurement, the kit delivers a measurable return on safety investments and helps meet project timelines and regulatory checks more reliably.
The kit includes a certificate and installation assembly parts, plus access to the manufacturer’s downloadable documentation set (PDF pages and instructions). After-sales support typically covers warranty considerations, access to further spare parts, and technical assistance for maintenance planning and future upgrades.
