Rittal 9686430 Arcing Fault Kit - Class B Safety
Part Number: 9686430
Manufacturer
Rittal
Part number
9686430
Category
Alt Part Number
SV 9686.430
Quick Summary
The Rittal 9686430 arcing fault kit provides Class B arc flash protection for VX rear-area enclosures. Engineers often face downtime and safety risks when upgrading panels, and this kit offers a ready-to-install solution with clearly labeled parts to minimize project friction. It aligns with arc-flash safety standards per IEC/TR 61 641 and ships with a formal certificate; the product is cataloged under ETIM EC002498 and ECLASS 27142423 for efficient procurement. By simplifying retrofits and standardizing components, it supports safer installations, faster commissioning, and lower total cost of ownership for panel builders and end users alike.
Product Information
Extended Description
9686430 Rittal: SV arcing fault kit, class B, for VX rear area
Article number
SV 9686.430
Design
For busbar system assembly in the rear section
Product description
To achieve arc flash class B (human safety and protection of equipment) to IEC/TR 61 641. Suitable for one enclosure panel.
Material
Steel | Plastic | Silicone
Supply includes
2 metal covers | 2 roof mounting brackets for sacrificial anodes | Certificate | Assembly parts | 8 sacrificial anodes | 6 seals | 6 plastic covers
Packs of
1 pc(s).
Customs tariff number
83024900
EAN
4028177962828
ETIM 9
EC002498
ECLASS 8.0
27142423
Product description
SV arcing fault kit, class B, for VX rear area
Feature → Business Impact → Application: SV 9686.430 is designed for busbar system assembly in the rear section, enabling safer, faster rear-area wiring and reducing arc-flash exposure during maintenance. The class B rating translates to measurable safety improvements for technicians working in VX enclosures, and the included certificate supports compliance documentation for audits. Feature → Business Impact → Application: The kit materials—steel, plastic, silicone—offer robust durability in harsh industrial environments, reducing replacement cycles and maintenance costs while preserving enclosure integrity. Feature → Business Impact → Application: Supplied items such as two metal covers, sacrificial anodes, seals, and assembly parts shorten installation time and eliminate guesswork, improving first-pass installation efficiency. Feature → Business Impact → Application: ETIM 9 EC002498 and ECLASS 8.0 27142423 alignment streamlines procurement, reduces cataloging errors, and enhances compatibility across supply chains. Feature → Business Impact → Application: The design supports one-enclosure-panel setups, minimizing footprint impact and enabling scalable upgrades across multiple VX systems.
Get a Quick Quote for a Rittal 9686430
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Rittal 9686430?
Enquire Now
FAQs
SV 9686.430 is specifically designed for busbar system assembly in the rear section of VX rear-area enclosures and is suitable for one enclosure panel, simplifying retrofits and reducing space concerns during upgrades.
The kit is engineered to achieve arc flash class B protection per IEC/TR 61 641, enhancing personnel safety and protecting critical equipment during maintenance and fault conditions without extensive panel redesign.
The package includes two metal covers, two roof mounting brackets for sacrificial anodes, a certificate, assembly parts, eight sacrificial anodes, six seals, and six plastic covers to support a complete, ready-to-install installation.
Certification-related references include IEC/TR 61 641 for arc flash class B, ETIM 9 EC002498, and ECLASS 8.0 27142423; the product also ships with an accompanying certificate and carries the EAN 4028177962828 for cataloging.
By providing a turnkey rear-area arc fault solution with labeled parts, included mounting brackets, and a certificate, the kit reduces installation time, minimizes downtime, and lowers maintenance costs over the enclosure’s life cycle.
