Rittal SV 9686.912 Connector Kit - E-Cu VX Top/Bottom
Part Number: 9686912
Manufacturer
Rittal
Part number
9686912
Category
Alt Part Number
SV 9686.912
Quick Summary
Rittal SV 9686.912 Connector Kit is designed for connecting open air circuit-breakers (ACB) and VX top/bottom sections. Engineers often struggle with finding compatible copper connectors and reliable transitions in compact VX panels. This solution aligns with ETIM EC001900 and ECLASS 27400613 classifications to ensure precise cataloging and procurement. By pairing E-Cu top/bottom connectors with VX software-driven design codes, you gain faster assembly and higher reliability, while keeping costs predictable. Secondary benefits include streamlined procurement workflows and improved panel performance for industrial automation and electrical distribution projects.
Product Information
Extended Description
9686912 Rittal: Connector kit E-Cu top/bottom, for VX
Article number
SV 9686.912
Product description
For the connection of open air circuit-breakers (ACB), coupling sections and cable transition sections.
Material
E-Cu
Note
Please quote the complete configuration code (configuration code = Model No. + design code) on all enquiries and orders. The required design code is generated by the VX25 Rittal Power Engineering software (www.rittal.com/rpevx/)
Packs of
1 pc(s).
Customs tariff number
74071000
EAN
4028177953567
ETIM 9
EC001900
ECLASS 8.0
27400613
Product description
Connector kit E-Cu top/bottom, for VX
E-Cu conductor material delivers high conductivity and low contact resistance, reducing thermal rise and improving long-term reliability. This translates to fewer maintenance cycles and lower life-cycle costs in demanding VX installations. Top/bottom connector kit for VX simplifies assembly, speeds up panel builds, and reduces field errors, yielding noticeable time savings during commissioning and a lower risk of mis-wiring in dense switchgear environments. Compatibility with VX25 design software ensures the complete configuration code can be generated, reducing ordering errors and enabling seamless integration with VX engineering workflows. Packaging of 1 piece per pack reduces inventory mistakes and simplifies procurement, supporting lean manufacturing and just-in-time installation in modern control panels. The kit is designed to connect open air circuit-breakers, coupling sections, and cable transitions, delivering reliable, scalable ACB connections in VX systems. Copper-based connectors support robust performance in harsh industrial environments, enhancing reliability and reducing unplanned downtime.
