003G1037
Part Number: 003G1037
Product Information
Extended Description
003G1037 Danfoss: SAF PB25 1-6 80cm2 red
Gross weight
11.347 Kilogram
Net weight
11.347 Kilogram
Volume
26.485 Liter
EAN
5702421808511
Actuator diaphragm material
EPDM (Rolling, fibre enforced)
Actuator size [cm²]
80 cm²
Body material
Steel, mat. No 1.0338, zinc plated and yellow chromate
China RoHS compliance
Out of scope
Contain batteries
No
Description
SAF PB25 1-6 80cm2 red
Differential pressure setting [bar] [Max]
6 bar
Differential pressure setting [bar] [Min]
1 bar
EU RoHS compliance
Out of scope
Flow control
No
Flow limitation
No
Media pH [Max]
10
Media pH [Min]
7
Media temperature [°C] [Max]
150 °C
Media temperature [°C] [Min]
2 °C
Medium alternative
Glycolic water up to 30%
Mounting version
Flow
Operating pressure [bar] [Max]
25 bar
Permissible media
District heating/cooling circulation water
Pressure class
PN 25
Pressure controller
Differential pressure controller
Pressure nominal [bar]
25 bar
Pressure setting range [bar] [Max]
6 bar
Pressure setting range [bar] [Min]
1 bar
Product group
Actuators - Pressure Flow
Setting Type
Adjustable
Type
SAF
UK RoHS compliance
Out of scope
