003L6013
Part Number: 003L6013
Product Information
Extended Description
003L6013 Danfoss: Self-acting constant flow valve
Gross weight
1.078 Kilogram
Net weight
0.858 Kilogram
Volume
1.094 Liter
EAN
5702420017099
Connection size in
Rp 1
Connection size out
R 1
Connection types
Threaded
Connections
1"
Contain batteries
No
Description
Self-acting constant flow valve
Design
Angle
Differential pressure range [bar] [Max]
0.5 bar
Flow temperature [°C] [Max]
120 °C
Inlet connection type
Internal thread
Outlet connection type
External thread
Product group
Automatic Bypass Control
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
7b37c0d6-8f7d-4b5c-b1b0-5f93cc0ad594
SCIP dossier product name
AVDO COMMERCIAL 25
Setting [bar] [Max]
0.5 bar
Setting [bar] [Min]
0.05 bar
Type
AVDO
Valve size
DN 25
Working pressure [bar] [Max]
10 bar
Automatic bypass control AVDO
AVDO - Installation and Commissioning Guide
Instructions for AVDO
Automatic By-pass Valve AVDO
AVDO Automatic Bypass Control Instructions
AVDO / AVDO accessories / AVDO bypass control
Danfoss MD VJLXA102.05
003L6013
AVDO_Angle_DN25_Tailpiece_003L6013_STEP
AVDO_Angle_DN25_Tailpiece_003L6013_2D
AVDO_Angle_DN25_Tailpiece_003L6013_3D
