003N0131
Part Number: 003N0131
Product Information
Extended Description
003N0131 Danfoss: AVTB Thermost.act 30-100 2,3m #9,5x150mm
Gross weight
0.42 Kilogram
Net weight
0.399 Kilogram
Volume
1.959 Liter
EAN
5702421100073
Ambient temperature [°C] [max]
70 °C
Ambient temperature [°C] [min]
0 °C
Capillary tube length [m]
2.3 m
China RoHS compliance
Out of scope
Contain batteries
No
Description
AVTB Thermost.act 30-100 2,3m #9,5x150mm
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Function
Temp. controller
Impulse tube material
Copper mat. No 2.0090
Media temperature at sensor [°C] [Max]
130 °C
Product group
Actuators - Temperature
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Sensor connection
M14x1 / R1/2 ext thread acc. DIN 2999
Temperature sensor diameter [mm]
9.5 mm
Temperature sensor length [mm]
150 mm
Temperature sensor material
Copper mat. No 2.0090
Temperature setting range [°C] [Max]
100 °C
Temperature setting range [°C] [Min]
30 °C
Time constant [sec]
25 "
Transport temperature [°C] [Max]
50 °C
Transport temperature [°C] [Min]
-20 °C
Type
AVTB
UK RoHS compliance
Out of scope
