003Z1222

Part Number: 003Z1222
003Z1222
Manufacturer
Danfoss
Part number
003Z1222
Category

Product Information

Extended Description

003Z1222 Danfoss: AB-QM DN15, High flow, without test plugs, pressure independent balancing and control valve
Gross weight
0.49 Kilogram
Net weight
0.46 Kilogram
Volume
0.902 Liter
EAN
5710104092065
Actuator connection
M30 x 1.5
China RoHS compliance
Out of scope
Connection types
External Thread
Contain batteries
No
Description
AB-QM DN15, High flow, without test plugs, pressure independent balancing and control valve
Differential pressure [kPa] [Max]
600 KPa
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Flow nominal [m=C2=B3/h]
1.135 m=C2=B3/h
Flow type
High flow
Media temperature [=C2=B0C] [Max]
120 =C2=B0C
Media temperature [=C2=B0C] [Min]
-10 =C2=B0C
Pressure class
PN 16
Product group
Pressure independent balancing and control valves
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
b2775c18-5d86-443c-ae8a-62cd3cf7389c
SCIP dossier product name
AB-QM DN15 HF PN16
Starting pressure [kPa]
35 KPa
Stroke [mm]
4 mm
Test plugs
Without test plugs
Type
AB-QM
UK RoHS compliance
Out of scope
Valve body material
DZR Brass (CW 602N)
Valve size
DN 15
Version
AB-QM 3.0
003Z0226
Tailpiece for welding DN 15 (1 pc.)
003Z0230
Brass shut-off and protection cap for AB-QM
003Z0232
Tailpiece with External thread DN 15
003Z0282
AB-QM 1/2" MNPT threaded tailpiece kit
003Z1271
INOX tailpiece for welding DN 15
003Z3962
AB-QM DN 150 Impulse tube set
