009L5395

Part Number: 009L5395
009L5395
Manufacturer
Danfoss
Part number
009L5395
Category

Product Information

Extended Description

009L5395 Danfoss: Max. Working Pressure [bar]: 90.0, Inlet connection type: Solder, ODF, Inlet size [mm]: 6.00, Outlet connection type: Solder, ODF, Outlet size [mm]: 6.00
Gross weight
0.173 Kilogram
Net weight
0.119 Kilogram
Volume
0.759 Liter
EAN
5715162512210
Access port
No
Approval
C UL US LISTED,LLC CDC TYSK,PED,UKCA
Body material
Stainless steel
Connection material
stainless steel SS tube
Contain batteries
No
Cv value [gal/min]
2.06 gal/min
Direction
Straightway
Equipment
Cap w. wire seal
Flow direction
Bi-flow
Flow direction indicator
Embossed 2-way arrow
Fluid Group
2
Ignition source assessment
Yes
Inlet connection type
Solder, ODF
Inlet size [mm]
6 mm
Kv value [m=C2=B3/h]
1.78 m=C2=B3/h
Max. Working Pressure [bar]
90 bar
Max. Working Pressure [psig]
1305 psig
Outlet connection type
Solder, ODF
Outlet size [mm]
6 mm
Packing format
Multi pack
PED category
Art. 4, par. 3
Product accessories
BM/GBC valve accessories
Product group
Shut-off and regulating valves
Product Name Description
Shut-off ball valve
Quantity per packing format
30 pc
Refrigerants
R744
Serviceable
No
Temperature range [=C2=B0C] [max]
100 =C2=B0C
Temperature range [=C2=B0C] [min]
-40 =C2=B0C
Temperature range [=C2=B0F] [max]
212 =C2=B0F
Temperature range [=C2=B0F] [min]
-40 =C2=B0F
Type
GBC 6s H
UL approved refrigerants
R744
UL evaluated
Yes
009L5209
Spare part, GBC 90bar V3 6s-12s, Seal cap
009L5213
Schrader valve, Spare part
Shut-off ball valve, type GBC (90 bar) and GBCT (140 bar) Shut-off ball valve Type GBC (90bar) Check valve, Shut-off diaphragm valve, shut-off ball valve and differential pressure valve Danfoss MD 033F4001.AH Danfoss MD 033F4006 Danfoss MD 033F4010 Danfoss MD 033F4017.AD TSSA CRN 0C24058.5267890TNY GBC 90 bar CO2 009L5415,009L5395 GBC 90 bar CO2 009L5415,009L5395 GBC 90 bar CO2 009L5415,009L5395
