013G0002

Part Number: 013G0002
013G0002
Manufacturer
Danfoss
Part number
013G0002
Category

Product Information

Extended Description

013G0002 Danfoss: Normal flow valves without presetting
Gross weight
0.216 Kilogram
Net weight
0.216 Kilogram
Volume
0.227 Liter
EAN
5702420013367
Application
2-pipe system
China RoHS compliance
Out of scope
Connection size in
Rp 3/8
Connection size out
R 3/8
Connection types
Internal thread
Contain batteries
No
Description
Normal flow valves without presetting
Design
Straight
Differential pressure range [bar] [Max]
0.6 bar
Dimension standard
F
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Finish
Nickel plated
Flow temperature [=C2=B0C] [Max]
120 =C2=B0C
Kv value at Xp =3D 0.5 - 2.0 K [m=C2=B3/h] [Max]
0.56 m=C2=B3/h
Kv value at Xp =3D 0.5 - 2.0 K [m=C2=B3/h] [Min]
0.17 m=C2=B3/h
Kvs values [m=C2=B3/h]
0.65 m=C2=B3/h
Presetting
no
Product group
Radiator Valves
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Tailpiece type
Standard
Test pressure [bar]
16 bar
Type
RA-FN
UK RoHS compliance
Out of scope
Valve size
DN 10
Valve type
Fixed capacity
Working pressure [bar] [Max]
10 bar
Mounting Danfoss Radiator Valves Dynamic Valve - Building owner brochure Dynamic Valve - Designer and installer brochure Product Overview - Radiator thermostats Case story Dynamic Valve=E2=84=A2 Sonderborg State school Engineering Tomorrow lowers apartments=E2=80=99 heating cost to less than $50 annually Fixed capacity valves type RA-FN, series D RA-FN radiator valves, series F Radiator valves type RA-FN (series D) and RA-G Tech Info EN 215 RA-FN Danfoss MD VJLXA102.05 DNV 7714-2016-PC-DEN-DANAK_Rev.11 RA-FN 013G0002 Radiator Valve RA-FN 013G0002 Radiator Valve RA-FN 013G0002 Radiator Valve RA-FN_Straight_DN10_F_013G0002_STEP RA-FN_Straight_DN10_F_013G0002_2D RA-FN_Straight_DN10_F_013G0002_ RA-FN_Straight_DN10-20_F_RFA RA-FN_Straight_DN10-20_F_Regus_RFA RA-FN_Straight_DN10-20_F_React_RFA RA-FN_Straight_DN10-20_F_Redia_RFA
