014-0005
Part Number: 014-0005
Product Information
Extended Description
014-0005 Danfoss: Max. Working Pressure [bar]: 35.0, Moisture indicator: No indicator, Connection type: NPT, Connection size: 3/4 in
Gross weight
0.094 Kilogram
Net weight
0.084 Kilogram
Volume
0.086 Liter
EAN
5702422052784
Body material
Brass
China RoHS compliance
Yes exceed limitations
Connection material
Brass
Connection size
3/4 in
Connection size [in]
3/4 in
Connection standard
ANSI/ASME B1.20.1
Connection type
NPT
Contain batteries
No
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Floating ball [pc]
1 pc
Lubricants compatibility
Oilfree applications
Max. Working Pressure [bar]
35 bar
Max. Working Pressure [psig]
500 psig
Moisture indicator
No indicator
Oil free refrigerants
R134a,R513A
Packing format
Multi pack
Product accessories
No
Product group
Sight glasses
Product Name Description
Sight glass socket
Quantity per packing format
19 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R1233zd(E),R1234yf,R1234ze(E),R134a,R22,R404A,R407A,R407C,R407F,R448A,R449A,R450A,R452A,R507A,R513A
SCIP dossier no.
525e07d8-f4a6-4108-b8f8-36090550941f
Serviceable
No
Temperature range [°C] [max]
80 °C
Temperature range [°C] [min]
-50 °C
Temperature range [°F] [max]
175 °F
Temperature range [°F] [min]
-58 °F
Type
SGR
UK RoHS compliance
Out of scope
