017-513466

Part Number: 017-513466
017-513466
Manufacturer
Danfoss
Part number
017-513466
Category

Product Information

Extended Description

017-513466 Danfoss: Regulation range [bar] Pe: 10.00 - 28.00, Differential [bar]: 1.50, Contact function: SPDT gold, Reset function: Manual Max, Pressure connection type: G, Pressure connection size: 3/8, Pressure Male/Female: Male, Enclosure rating IP: IP54, Max. Working Pressure [bar]: 34.0
Gross weight
1.24 Kilogram
Net weight
1.126 Kilogram
Volume
2.685 Liter
EAN
5702428130813
Ambient temperature range [°C] [max]
65 °C
Ambient temperature range [°C] [min]
-20 °C
Ambient temperature range [°F] [max]
149 °F
Ambient temperature range [°F] [min]
-4 °F
Approval
ATEX - Cat. 2 - Zone 1,CCC,CE,EAC,LLC CDC EURO-TYSK,PED,PZH,RMRS,RoHS,RoHS China,TYSK
Burst pressure [bar]
136 bar
CE evaluated
Yes
China RoHS compliance
Yes
Contact function
SPDT gold
Contact rating
Ci=0.5 nF,Ii=0.5 A,Li=0.2 uH,Pi=1 W,Ui=29 V
Contain batteries
No
Differential [bar]
1.5 bar
Differential [psi]
14.5 psi
Electrical conn. Male/Female
Female
Electrical connection
Screwed cable entry
Electrical connection size
2xPg 13.5
Electrical connection standard
DIN 40430
Electrical spec. standard
EN 60947-4/-5
EN 60947 electrical properties
Insulation: 400V,Pollution degree: 3,Rated impulse voltage: 4 kV,Short circuit prot, fuse: 10A
EN 60947 wiring properties
Flex, ferrules: 0.2-1.5 mm2,Flex, no ferrules: 0.2-2.5 mm2,Solid/stranded: 0.2-2.5 mm2
Enclosure rating IP
IP54
EU RoHS compliance
Out of scope
EX Sales text
-20Cta+65C,II 2G Ex ia IIC T6...T1 Gb
Fluid Group
1
Max. test pressure [bar] Pe
38 bar
Max. test pressure [psig]
551 psig
Max. Working Pressure [bar]
34 bar
Max. Working Pressure [psig]
495 psig
Packing format
Multi pack
PED category
IV
Pressure connection notes
Weld nipple d6.5/D10mm
Pressure connection size
3/8
Pressure connection standard
ISO 228-1
Pressure connection type
G
Pressure Male/Female
Male
Pressure sensing element
Bellows
Product accessories
Switches accessories
Product description
Pressure Switch
Product group
Switches and thermostats
Product Name Description
Pressure switch
Quantity per packing format
15 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Regulation range [bar] Pe [max]
28 bar
Regulation range [bar] Pe [min]
10 bar
Regulation range [psig] Pe [max]
406.1 psig
Regulation range [psig] Pe [min]
145 psig
Reset function
Manual Max
SCIP dossier no.
54f3e4b2-77e8-4825-a1c1-c3d5ba584171
Serviceable
Contact systems
Type
RT6AEB
UK RoHS compliance
Out of scope
Pressure switch Differential pressure switch and Thermostat RT-E Pressure switch Type RT, Spare parts and accessories Pressure switch, RT 1AE, RT 6AEW, RT 6AEB, RT 6AES, RT 116E, RT 5E, RT 117E, RT 112E, RT 113E, RT 121E, RT 260AE, RT 262AE Danfoss EU 060-9655.AG DEMKO 14 ATEX 1406X Rev. 4 IECEx DK/ULD/QAR12.0002/11 IECEx ULD 14.0013X_04 UL21UKEX2021X Pressure switches & Thermostats Danfoss MD 017R9607.AC Danfoss MD 060-9639.AB TÜV 01 202 969 B-21-0013 01 TÜV 0879-PESR-B(P)-21484-12-DE RT6AES/B/W Pressure switch , G3/8 weld nipple, code 017-502166 RT-E pressure control RT6AEB Pressure switch RT6AEB Pressure switch
