018F4112

Part Number: 018F4112
018F4112
Manufacturer
Danfoss
Part number
018F4112
Category

Product Information

Extended Description

018F4112 Danfoss: Electrical connection: Conduit hub, Supply voltage [V] AC: 110, Frequency [Hz]: 50/60 Hz, Enclosure rating IP: IP54
Gross weight
0.349 Kilogram
Net weight
0.325 Kilogram
Volume
0.292 Liter
EAN
5702428840965
Actuator size
13.5 mm
Ambient temperature range [°C] [max]
50 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
120 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
C UL US LISTED,LLC CDC TYSK
Cable length [in]
20 in
Cable length [m]
0.5 m
China RoHS compliance
Out of scope
Coil connection
1/2 in Conduit Hub
Coil design standard
UL 429
Coil fastening
Clip-on
Coil winding insulation class
Class H to IEC 85
Colour
Black
Compliance
UL 429
Contain batteries
No
Electrical conn. comments
Flying leads
Electrical connection
Conduit hub
Electrical connection size
1/2 in
Electrical connection standard
UL50E CLASS 4
Enclosure rating IP
IP54
Enclosure rating Nema (~)
4
EU RoHS compliance
Out of scope
Frame design
Ext. metal frame
Frequency [Hz]
50/60 Hz
Packing format
Multi pack
Parts Program name
EV210B,EV215B,EV220B 15 - 50,EV220B 6 - 22,EV225B,EV245B,EV250B
Pollution degree
3
Power consumption [W] 50Hz
16 W
Power consumption [W] 60Hz
15 W
Product accessories
Solenoid coil accessories
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
35 pc
REACH Candidate List substances
No
Rel. Humidity [% RH] [max]
97 %
Rel. Humidity [% RH] [min]
0 %
Rel. Humidity conditions
Non-condensation
Serviceable
No
Spare part number
018F4112
Supply voltage 50Hz Max [V]
110 V
Supply voltage 60Hz Max [V]
120 V
Supply voltage 60Hz Min [V]
110 V
Supply voltage [V] AC
110 V
Type
BX120CS
Type designation
BX120CS
UK RoHS compliance
Out of scope
UL approval file name
MH29671
UL evaluated
Yes
