018F4721
Part Number: 018F4721
Product Information
Extended Description
018F4721 Danfoss: Electrical connection: DIN Spade, Enclosure rating IP: IP00
Gross weight
0.288 Kilogram
Net weight
0.249 Kilogram
Volume
0.271 Liter
EAN
5715162268896
Actuator size
13.5 mm
Ambient temperature range [°C] [max]
50 °C
Ambient temperature range [°C] [min]
-25 °C
Ambient temperature range [°F] [max]
122 °F
Ambient temperature range [°F] [min]
-13 °F
Approval
DNV∙GL
China RoHS compliance
Out of scope
Coil connection
DIN Spade
Coil design standard
VDE 0580
Coil fastening
Clip-on
Coil winding insulation class
Class H to IEC 85
Colour
Black
Compliance
EN 60730-1
Contain batteries
No
Duty rating
Continuous
Electrical connection
DIN Spade
Electrical connection size
6.3 mm x 0.8 mm
Electrical connection standard
EN175301-803
Electrical connector
3 x spades
Enclosure rating IP
IP00
EU RoHS compliance
Out of scope
Packing format
Multi pack
Power consumption [W] DC
16 W
Product accessories
Solenoid coil accessories
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
50 pc
Rel. Humidity [% RH] [max]
97 %
Rel. Humidity [% RH] [min]
0 %
Rel. Humidity conditions
Non-condensation
Spare part number
018F4721
Supply voltage [V] DC
24 V
Type
BR024DS
Type designation
BR024DS
UK RoHS compliance
Out of scope
