018F6783

Part Number: 018F6783
018F6783
Manufacturer
Danfoss
Part number
018F6783
Category

Product Information

Extended Description

018F6783 Danfoss: Electrical connection: Terminal box, Supply voltage [V] AC: 208 - 240, Frequency [Hz]: 50/60 Hz, Enclosure rating IP: IP67
Gross weight
0.386 Kilogram
Net weight
0.371 Kilogram
Volume
0.417 Liter
EAN
5702428490207
Actuator size
13.5 mm
Ambient temperature range [°C] [max]
55 °C
Ambient temperature range [°C] [min]
-25 °C
Ambient temperature range [°F] [max]
130 °F
Ambient temperature range [°F] [min]
-13 °F
Approval
CE,EAC,LLC CDC TYSK,UKCA
CE evaluated
Yes
China RoHS compliance
Out of scope
Coil fastening
Clip-on
Colour
Blue
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection
Terminal box
Electrical connection size
Pg 13.5
Enclosure rating IP
IP67
EU RoHS compliance
Out of scope
Frequency [Hz]
50/60 Hz
In scope of WEEE
Yes
Packing format
Multi pack
Parts Program name
EV210B,EV212B,EV220B 15 - 50,EV220B 6 - 22,EV220B 65 - 100,EV222B,EV224B,EV227B,EV250B,EV251B
Power consumption [W] 50Hz
4 W
Power consumption [W] 60Hz
4 W
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
30 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
6a76eb5e-6ca8-43d3-be03-8320fd28438e
SCIP dossier product name
AKV 20/EVR 32-40/EVRH 40
Spare part number
018F6783
Supply voltage 50Hz Max [V]
240 V
Supply voltage 50Hz Min [V]
208 V
Supply voltage 60Hz Max [V]
240 V
Supply voltage 60Hz Min [V]
208 V
Supply voltage [V] AC [max]
240 V
Supply voltage [V] AC [min]
208 V
Type
BE240CS
Type designation
BE240CS
UK RoHS compliance
Out of scope
Used for product
AKV10, AKVH10
Solenoid coil type BB, BE, BF, BG, and BN Solenoid coils Type BA, BD, BB, BE, BF, BG, BN, BO, BJ, BX, BY, BQ, AM, AZ, AS and AP Solenoid coil Types BB, BE, BF, BG, and BN Solenoid coil with electronic coil controller Type EEC Danfoss EU-UK 033F0688.AJ EEC electronic coil controller EEC electronic coil controller BE_Voltage 12-24-230V_RFA Coil for EEC 208 Coil for EEC 208
