018Z6824
Part Number: 018Z6824
Product Information
Extended Description
018Z6824 Danfoss: Electrical connection: Terminal box, Supply voltage [V] AC: 230, Frequency [Hz]: 50 Hz, Enclosure rating IP: IP00
Gross weight
0.618 Kilogram
Net weight
0.559 Kilogram
Volume
0.542 Liter
EAN
5702428053532
Actuator size
13.5 mm
Ambient temperature range [°C] [max]
80 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
175 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
CE,EAC,LLC CDC TYSK,UKCA
Cable diameter [mm] [max]
11 mm
Cable diameter [mm] [min]
6 mm
CE evaluated
Yes
China RoHS compliance
Out of scope
Coil connection
Connection Box
Coil fastening
Clip-on
Colour
Blue
Conductor area [mm2]
0.75 - 1.5 mm2
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection
Terminal box
Electrical connection size
Pg 13.5
Electrical connector
Screwed cable entry
Enclosure rating IP
IP00
Enclosure rating Nema (~)
0
EU RoHS compliance
Out of scope
Frequency [Hz]
50 Hz
In scope of WEEE
Yes
Packing format
Multi pack
Power consumption 50Hz [VA]
13 VA
Power consumption [W] 50Hz
7 W
Product accessories
Solenoid coil accessories
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
25 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Rel. Humidity [% RH] [max]
97 %
Rel. Humidity [% RH] [min]
0 %
Rel. Humidity conditions
Non-condensation
SCIP dossier no.
23785618-b379-4da7-a913-ecd40c8fae6d
SCIP dossier product name
Solenoid coils
Serviceable
No
Spare part number
018Z6824
Supply voltage 50Hz Max [V]
230 V
Supply voltage [V] AC
230 V
Type
BG230A
Type designation
BG230A
UK RoHS compliance
Out of scope
