023U7339
Part Number: 023U7339
Product Information
Extended Description
023U7339 Danfoss: Core Size code: 144 cu.in., Connection material: Copper, Connection Solder size [in]: 1 5/8 in
Gross weight
8.234 Kilogram
Net weight
7.869 Kilogram
Volume
21.864 Liter
EAN
5715162705520
Approval
UL
Body material
Steel
Braket
No
Brand
ELIMINATOR
Connection material
Copper
Connection Solder size [in]
1 5/8 in
Connection type
Solder, ODF
Contain batteries
No
Core Size code
144 cu.in.
Cover
Plug
Flow direction indicator
Label printed 1-way arrow
Fluid Group
I,II
Liq Cap [Kw]
R1234yf: 257.8,R32: 542.4,R444B: 413.4,R452B: 452.1,R454B: 462.8
Liq Cap [TR]
R1234yf: 73.3,R32: 154.2,R444B: 117.6,R452B: 128.6,R454B: 131.6
LiqCap Cond (ARI 710-2009)[SI]
Delta p=0.07bar,tliq= 30°C,tvap=-15°C
LiqCapCond (ARI 710-2009)[IMP]
Delta p=1psi,tliq= 86°F,tvap=5°F
Lubricants compatibility
Oilfree applications
Max. Working Pressure [bar]
46 bar
Max. Working Pressure [psig]
667 psig
MWP comments
35_bar/508_psig_as_receiver,35_bar/508_psig_with_48-F
Net volume [foz US]
120.96 Fluid Ounce US
Net volume [l]
3.577 L
Number of cores
3
Oil free refrigerants
R1234ze(E),R516A
Packing format
Single pack
Parts included
1 cov,6 felt gaskets,8 Bolts
Parts Program name
DCR
Product accessories
DCR accessories
Product description
Refrigerant Filter Drier
Product group
Filter driers
Product Name Description
Filter drier, shell
Quantity per packing format
1 pc
REACH Candidate List substances
No
Refrigerants
R1234yf,R1234ze(E),R32,R444B,R452B,R454A,R454B,R454C,R455A,R457A,R516A
Serviceable
DCR spare parts
Shell volume [foz US]
164.29 Fluid Ounce US
Shell volume [l]
4.85 L
Temperature range [°C] [max]
70 °C
Temperature range [°C] [min]
-40 °C
Temperature range [°F] [max]
160 °F
Temperature range [°F] [min]
-40 °F
Type
DCR/H
Type designation
DCR 14413s/H
UL approval file name
SA6398
UL approved refrigerants
R1234yf,R1234ze(E),R32,R444B,R452B,R454A,R454B,R454C,R455A,R457A,R516A
UL evaluated
Yes
