023U7342

Part Number: 023U7342
023U7342
Manufacturer
Danfoss
Part number
023U7342
Category

Product Information

Extended Description

023U7342 Danfoss: Core Size code: 48 cu.in., Connection material: Copper, Connection Solder size [in]: 7/8 in, Connection Solder size [mm]: 22.00
Gross weight
4.961 Kilogram
Net weight
4.932 Kilogram
Volume
11.408 Liter
EAN
5715162705490
Approval
UL
Body material
Steel
Braket
No
Brand
ELIMINATOR
Connection material
Copper
Connection Solder size [in]
7/8 in
Connection Solder size [mm]
22 mm
Connection type
Solder, ODF
Contain batteries
No
Core Size code
48 cu.in.
Cover
Plug
Flow direction indicator
Label printed 1-way arrow
Fluid Group
I,II
Liq Cap [Kw]
R1234yf: 92,R32: 193.5,R444B: 147.5,R452B: 161.3,R454B: 165.1
Liq Cap [TR]
R1234yf: 26.2,R32: 55,R444B: 41.9,R452B: 45.9,R454B: 46.9
LiqCap Cond (ARI 710-2009)[SI]
Delta p=0.07bar,tliq= 30°C,tvap=-15°C
LiqCapCond (ARI 710-2009)[IMP]
Delta p=1psi,tliq= 86°F,tvap=5°F
Lubricants compatibility
Oilfree applications
Max. Working Pressure [bar]
46 bar
Max. Working Pressure [psig]
667 psig
Net volume [foz US]
50.44 Fluid Ounce US
Net volume [l]
1.492 L
Number of cores
1
Oil free refrigerants
R1234ze(E),R516A
Packing format
Single pack
Parts included
1 cov,2 felt gaskets,8 Bolts
Parts Program name
DCR
Product accessories
DCR accessories
Product description
Refrigerant Filter Drier
Product group
Filter driers
Product Name Description
Filter drier, shell
Quantity per packing format
1 pc
REACH Candidate List substances
No
Refrigerants
R1234yf,R1234ze(E),R32,R444B,R452B,R454A,R454B,R454C,R455A,R457A,R516A
Serviceable
DCR spare parts
Shell volume [foz US]
65.76 Fluid Ounce US
Shell volume [l]
1.94 L
Temperature range [°C] [max]
70 °C
Temperature range [°C] [min]
-40 °C
Temperature range [°F] [max]
160 °F
Temperature range [°F] [min]
-40 °F
Type
DCR/H
Type designation
DCR 0487s/H
UL approval file name
SA6398
UL approved refrigerants
R1234yf,R1234ze(E),R32,R444B,R452B,R454A,R454B,R454C,R455A,R457A,R516A
UL evaluated
Yes
Strainers - Industrial Refrigeration product group catalogue Filter drier, shell types DCR and DCRE Filter Driers 023U and 023Z UL SA6398 19980330 US-CA DM core for DCR filter drier 48-DM filter drier core, code number 023U1391 DCR solid core
