030H8026
Part Number: 030H8026
Product Information
Extended Description
030H8026 Danfoss: 1.35GAL 80HD
Gross weight
0.031 Kilogram
Net weight
0.025 Kilogram
Volume
0.017 Liter
EAN
5702425063961
Approval
CE
Capacity [kg/h]
5.26 kg/h
Capacity [l/h]
0 L/h
Capacity [USgal/h]
1.35 gal/h
CE evaluated
Yes
CEN
Yes
China RoHS compliance
Out of scope
Contain batteries
No
Description
1.35GAL 80HD
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Filter grade [µm]
30-40
Filter type
Sinter
LE anti-drip valve
No
Material type
Steel
Packing format
Single pack
Product group
Oil Nozzles
Quantity per packing format
12 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Reference point
7 bar, 3.4 cSt, 820 kg/m³
SCIP dossier no.
752c33e5-e7ce-4fc7-a03f-19be3adeaa1a
SCIP dossier product name
D-Steel Nozzles - HD
Shape
Round
Specification point
10 bar, 3.4 cSt, 840 kg/m³
Spray angle [°]
80 °
Spray pattern
Hollow
spray pattern marking
HD
Type
HD
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
18
UL evaluated
Out of scope
030-0522
1/4" BSP, NOZZLE HOLDER
030-0523
1/8" BSP, NOZZLE HOLDER
