030H8034
Part Number: 030H8034
Product Information
Extended Description
030H8034 Danfoss: 2.25GAL 80HD
Gross weight
0.031 Kilogram
Net weight
0.025 Kilogram
Volume
0.017 Liter
EAN
5702425063060
Approval
CE
Capacity [kg/h]
8.6 kg/h
Capacity [l/h]
0 L/h
Capacity [USgal/h]
2.25 gal/h
CE evaluated
Yes
CEN
No
China RoHS compliance
Out of scope
Contain batteries
No
Description
2.25GAL 80HD
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Filter mesh
120
Filter type
Stainless strainer
LE anti-drip valve
No
Material type
Steel
Packing format
Single pack
Product group
Oil Nozzles
Quantity per packing format
12 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Reference point
7 bar, 3.4 cSt, 820 kg/m³
SCIP dossier no.
752c33e5-e7ce-4fc7-a03f-19be3adeaa1a
SCIP dossier product name
D-Steel Nozzles - HD
Shape
Round
Specification point
10 bar, 3.4 cSt, 840 kg/m³
Spray angle [°]
80 °
Spray pattern
Hollow
spray pattern marking
HD
Type
HD
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
18
UL evaluated
Out of scope
030-0522
1/4" BSP, NOZZLE HOLDER
030-0523
1/8" BSP, NOZZLE HOLDER
Oil Nozzles - End User leaflet
Oil nozzles for your service
Practical tips oil nozzle
HFD-HD and SFD-SD Nozzle Datasheet
Oil Nozzles Types HFD/HD and SFD/SD
Soft value overview_Oil Pumps_Controls_Nozzles_PL02
Service Manual Danfoss Burner Components
Soft value overview_Oil Pumps_Controls_Nozzles_PL02
Service Handbook Danfoss Burner Components
Oil Nozzles
HD 030H4022
