030H8316
Part Number: 030H8316
Product Information
Extended Description
030H8316 Danfoss: 0.75GAL 80EH
Gross weight
0.032 Kilogram
Net weight
0.031 Kilogram
Volume
0.024 Liter
EAN
5702425021251
Approval
CE
Capacity [kg/h]
2.25 kg/h
Capacity [l/h]
0 L/h
Capacity [USgal/h]
0.75 gal/h
CE evaluated
Yes
CEN
No
China RoHS compliance
Out of scope
Contain batteries
No
Description
0.75GAL 80EH
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a),6(a)-I,6(c)
Filter grade [µm]
45
Filter type
Sinter
LE anti-drip valve
No
Material type
Brass
Packing format
Industrial pack
Product group
Oil Nozzles
Quantity per packing format
10 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Reference point
7 bar, 3.4 cSt, 820 kg/m³
SCIP dossier no.
128fcc57-49a6-4de2-b90b-f71eda76684c
SCIP dossier product name
30 H F E - Nozzle 0.65-1.10 gph
Shape
Conical
Specification point
8.0 bar, 1.65 cSt, 790 kg/m³
Spray angle [°]
80 °
Spray pattern
Hollow
spray pattern marking
EH
Type
EH
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
12,18
UL evaluated
Out of scope
030-0072
SINTERED FILTER 45UM (50 PCS PACK)
030-0522
1/4" BSP, NOZZLE HOLDER
030-0523
1/8" BSP, NOZZLE HOLDER
