032B1016
Part Number: 032B1016
Product Information
Extended Description
032B1016 Danfoss: Inlet size [mm]: 16.00, Inlet connection type: Solder, ODF, Outlet size [mm]: 16.00, Outlet connection type: Solder, ODF
Gross weight
0.145 Kilogram
Net weight
0.144 Kilogram
Volume
0.138 Liter
EAN
5702428817066
Approval
C UL US LISTED,EAC,LLC CDC EURO-TYSK
Body material
Copper
China RoHS compliance
Yes exceed limitations
Connection material
Copper
Contain batteries
No
Cv value [gal/min]
3.35 gal/min
Design
Magnetic
Direction
Straightway
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(b),6(c)
Flow direction
Single-flow
Flow direction indicator
Laser engraved 1-way arrow
Inlet connection type
Solder, ODF
Inlet size [in]
5/8 in
Inlet size [mm]
16 mm
Kv value [m=C2=B3/h]
2.9 m=C2=B3/h
Max. Working Pressure [bar]
45 bar
Max. Working Pressure [psig]
653 psig
Outlet connection type
Solder, ODF
Outlet size [in]
5/8 in
Outlet size [mm]
16 mm
Packing format
Multi pack
Product group
Check valves
Product Name Description
Check valve
Quantity per packing format
72 pc
REACH Candidate List substances
No
Refrigerants
R1233zd(E),R1234yf,R1234ze(E),R1270,R134a,R22,R290,R404A,R407A,R407C,R407F,R407H,R410A,R448A,R449A,R449B,R450A,R452A,R452B,R454A,R454B,R454C,R455A,R507,R513A,R515B,R516A,R600,R600a
Temperature range [=C2=B0C] [max]
155 =C2=B0C
Temperature range [=C2=B0C] [min]
-50 =C2=B0C
Temperature range [=C2=B0F] [max]
311 =C2=B0F
Temperature range [=C2=B0F] [min]
-58 =C2=B0F
Type
CCV 16s
UL approval file name
REFRIGERANT VALVE 53R0
UL evaluated
Yes
